Eachine LAL5 225mm 5 Inch 4K 6S FPV Racing Drone PNP F405 Bluetooth FC Caddx Tarsier V2 Cam 2507 1850KV 50A Blheli_32 3-6S 5.8 Ghz 25-800m W VTX6/7 Inch Frame Arm, Click here. More spare Parts of LAL5, Click here. Specifications: Brand Name: Eachine Item Name: LAL5 225mm 5 Inch 4K 6S FPV Racing Drone Wheelbase: 225mm Weight: 411.8g (without battery) Package

Size: 270x 270x 160mm Package weight: 1034.7g Frame Wheelbase: 225mm Arm thickness: 5mm X plate: 2mm Bottom plate: 2mm Upper plate: 2mm Motor Mode: 2507KV: 1850 Idle current (IO/10V): 1.42 A No.of Cells (Lipo): 3-6 S Peakcurrent: 45 A Max. power: 1080 W Max. thrust: 1750g (6s/5) Configu-ration:12N14 P Internal Resistance:0.0398 Stator diameter: 25mm Stator thickness: 7mm
Height: 19.5mm
Width: 31mm Shaft diameter: 5mm Motor mount hole

Size: M3 Recommend propeller: 5-7 Inch Weight: 43g ESC50A 3-6S DSHOT1200 4 IN 1 ESCContinue current: 50 A Burst current: 60A (10s) Input voltage: 3-6SBEC: NO Current sensor: YESMain control chip: STM32F051 Mos chip: TPH1R403 Firmware: Blheli_32 Support DSHOT 150/300/600/1200/MULTISHOT/PWM/ONESHOTMOS:5 * 6 Galvanometer: None Weight: 13.5g Installation hole: 30.5x 30.5mm/3 Dimension: 49 *37mm Flight Controller EACHINE Customized LAL-F405 Bluetooth Flight Controller STM32F405 Chip MPU: MPU6000 (via SPI) Input voltage: support 2-6S Lipo input Onboard Bluetooth module, support APP configuration via smartphone Firmware: MATEKF405 Onboard German Bosch BMP280 high precision barometer Flight control onboard OSD chip, suppo





...

Eachine LAL5 228mm 4K FPV Racing Drone Spare Part F405 Bluetooth Flight Controller Specification:EACHINE Customized LAL-F405 Bluetooth Flight Controller STM32F405 Chip MPU: MPU6000 (via SPI) Input voltage: support 2-6S Lipo input Onboard Bluetooth module, support APP configuration via smartphone Firmware: MATEKF405 Onboard German Bosch BMP280 high precision barometer Flight control onboard OSD chip, support DMA mode (use F4 MCU to control OSD), you can use Beta Flight to adjust soft Piece adjustment parameter Built-in 5v/2A; 10V/2A BEC output Reserve Micro SD Black Box Reserve 5 serial ports & I2C interface for convenient GPS access (Bluetooth occupies TX5.RX5) Supports multiple types of receivers (eg SBUS, SUMH, SUMD, SPEKTRUM1024/2048, XBUS, PPM, etc. Type of receiver) With LED programming signal output port, support programmable LED light strip, can be adjusted by flying control with color & flash mode Has a voltage monitoring port (BAT) & a current monitoring port (CRT) to monitor battery voltage & current (requires additional power) Flow meter) With buzzer output port, support for external alarm buzzer for sound warning or notification of aircraft flight status Onboard 10V BEC, providing a cleaner image display All interfaces are available in socket & pad options for different people Support for betaflight/inav racing firmware
Size: 37x 37mm Mounting hole: 30.5x 30.5mm Weight: 6.1g Package Included:1 x F405 Bluetooth Flight Controller
...

Eachine LAL5 228mm 4K FPV Racing Drone Spare Part 225mm Wheelbase 5mm Arm Frame Kit Specification: Brand name: Eachine Wheelbase: 225mm Arm thickness: 5mm X plate: 2mm Bottom plate: 2mm Upper plate: 2mm Weight: 108.3g Package Included:1 x 228mm Frame Kit ...

Eachine LAL5 228mm 4K FPV Racing Drone Spare Part 2mm X Plate for Frame Kit Specification: Brand name: Eachine Item name: 2mm X Plate Suitable for Eachine LAL5 228mm 4K FPV Racing Drone Package Included:1 x 2mm X Plate ...

Eachine LAL5 228mm 4K FPV Racing Drone Spare Part 3D Printed FPV Camera Part Fixed Mount Specification: Brand name: Eachine Item name: 3D Printed FPV Camera Part Fixed Mount Suitable for Eachine LAL5 228mm 4K FPV Racing Drone Package Included:1 x 3D Printed FPV Camera Part Fixed Mount ...

Eachine LAL5 228mm 4K FPV Racing Drone Spare Part 50A Blheli_32 3-6S Brushless ESC w/ 35v 470uf Capacity Specification: Brand name: Eachine Continue current: 50 A Burst current: 60A (10s) Input voltage: 3-6SBEC: NO Current sensor: YESMain control chip: STM32F051 Mos chip: TPH1R403 Firmware: Blheli_32 Support DSHOT 150/300/600/1200/MULTISHOT/PWM/ONESHOTMOS:5 * 6 Galvanometer: None Weight: 13.5g Installation hole: 30.5x 30.5mm/3 Dimension: 49 *37mm Package Included:1 x 50A Blheli_32 3-6S Brushless ESC1 x Capacity 1 x Cable wire ...

Eachine LAL5 228mm 4K FPV Racing Drone Spare Part 5mm Arm Plate for Frame Kit Specification: Brand name: Eachine Item name: 5mm arm plate Meterail: Carbon fiber Suitable for Eachine LAL5 228mm 4K FPV Racing Drone Weight: 11g Package Included:1 x 5mm arm plate ...

Eachine LAL5 228mm 4K FPV Racing Drone Spare Part Cable Wire Set Specification: Brand name: Eachine Item name: Cable Wire Set Suitable for Eachine LAL5 228mm 4K FPV Racing Drone Package Included:1 x Cable Wire Set ...

Eachine LAL5 228mm 4K FPV Racing Drone Spare Part Frame 2mm Upper Plate Specification: Brand name: Eachine Item name: 2mm Upper Plate Suitable for Eachine LAL5 228mm 4K FPV Racing Drone Package Included:1 x 2mm Upper Plate ...

Eachine LAL5 228mm 4K FPV Racing Drone Spare Part Frame Kit 2mm Bottom Plate Specification: Brand name: Eachine Item name: 2mm Bottom Plate Suitable for Eachine LAL5 228mm 4K FPV Racing Drone Package Included:1 x 2mm Bottom Plate ...
