Eachine LCD5802D 5802 800*480 7 Inch 5.8G 40CH FPV Diversity Monitor with DVR Build-in Battery + Realacc 5d Bi 8d Bi Pogoda TFP-Mini Triple Feed Patch LHCP/RHCP Antenna Notice: If the monitor cant record the PAL format video or the image is not complete, please update it as follow:1. Download the file: Upgraded Fileand put it in Root of TF card 2. Turn on the monitor, it will auto update as thevideoshows. Notice: Before you use it, you should format your SD card to FAT32. There is a screen protector with H on screen, you can remove it.LCD5802D Monitor Description: User Manual Brand Name: Eachine Item Name: LCD5802D Monitor Built-in 5.8 Ghz Dual diversity receiver automatically for best reception Built-in 2CH 5.8 Ghz AV output & 1CH AV input Built-in high performance Li-POLYMER Battery:2000m AH/7.4 V Work status OSD display:RSSI indication ; Battery indicator; Channel indication A key to automatic signal search Support Chinese & English menu Format: JPEG, AVIScreen
Size:7 Screen type:TFT LCD Screen/long life, LED backlight Resolution: 800*480 Brightness:600cd/m 2 View Angle:140/120degree (Horizontal/ Vertical)
Size:180mm x 120mm x 25mm (Note: Sunshield
Height:110mm) Working Voltage:DC 7~16 V Power Consumption:max 650 m A @12 V Battery charging current:850m A @12V (max ) Working temperature:-10℃~+ 65 ℃ Connectors:RP-SMA female (outer needle) Antennas Connectors:RP-SMA male (inner hole) Support up to 32G, C10 SD Card.
Features: With DVR function Built-in Dual Receiver for best reception Dual buffered AV outputs Not affe



...

Eachine LCD5802S 5802 40CH Raceband 5.8G 7 Inch Diversity Receiver Monitor with Build-in Battery Description: Brand Name: Eachine Item Name: LCD5802S Monitor Built-in 5.8 Ghz Dual diversity receiver automatically for best reception Built-in 2CH 5.8 Ghz AV output & 1CH AV input Built-in high performance Li-POLYMER Battery:?2000m AH/7.4 V Work status OSD display?:?RSSI indication ; Battery indicator; Channel indication A key to automatic signal search Support Chinese & English menu Sensitivity: -90d Bm Screen
Size:7 Screen type:TFT LCD Screen/long life, LED backlight Resolution: 800*480 Brightness:?600cd/m 2 View Angle:140/120degree (Horizontal/ Vertical)
Size:180mm x 120mm x 50mm (Note: Sunshield
Height:28mm) Working Voltage:?DC 7~16 V Power Consumption:?max 650 m A @12 V Battery charging current?:?850m A @12V (max ) Working temperature:?-10℃~+ 65 ℃ Connectors:RP-SMA female (outer needle) Antennas Connectors:RP-SMA male (inner hole)
Features: Built-in Dual Receiver Automatically for best reception Automatic Antenna Switching Dual buffered AV outputs Not affect by 2.4 G Hz R/C Radios AV Receiver with Diversity inputs Small, light weight, durable 5 Bands & total 40 Channels Built-in battery, easy to carry & outdoor use A key to automatic signal search, Simple operation Work status OSD display: Always be aware of the device working condition. Notice: It cant receive 2 different channels at the same time Band & Channel selection?????CH?????CH?1CH?2CH?3CH?4CH?5CH?6CH?7CH?8GROUPA5865?MHZ5845?MHZ5825?MHZ5805?MHZ5785?MHZ5765



...

Eachine Lizard 105s FPV Racing Drone Spare Part 1106 5200KV Brushless Motor Specification: Brand name: Eachine Item name: 1106 5200KV Brushless Motor Suitable for Lizard 105s FPV Racing Drone Package Included:1 x 1106 5200KV Brushless Motor ...

Eachine Lizard 105S FPV Racing Drone Spare Part 3K Carbon Arm Specifications: Brand: Eachine Item name: 3K Carbon Frame arm Usage for Eachine Lizard 105 S Package include:4 x 3K Carbon Frame arm ...

Eachine Lizard 105S FPV Racing Drone Spare Part 3K Carbon Bottom Plate Specifications: Brand: Eachine Item name: 3K Carbon bottom plate Usage for Eachine Lizard 105 S Package include:1 x 3K Carbon bottom plate ...

Eachine Lizard 105S FPV Racing Drone Spare Part Battery Cable Ties Specifications: Brand: Eachine Item name: Battery Cable Ties Usage for Eachine Lizard 105 S Package include:1 x Battery Cable Ties ...

Eachine Lizard 105S FPV Racing Drone Spare Part Camera Mount Holder Specifications: Brand: Eachine Item name: Camera mount holder Usage for Eachine Lizard 105 S Package include:1 x Camera mount holder 1 x Nylon fixed column ...

Eachine Lizard 105S FPV Racing Drone Spare Part CNC Alloy Front Rear Stiffener Specifications: Brand: Eachine Item name: CNC Alloy Front & Rear stiffener Usage for Eachine Lizard 105 S Package include:CNC Alloy Front & Rear stiffenerx 2pcs ...

Eachine Lizard 105S FPV Racing Drone Spare Part Hexgonal Columns Microsoft Internet Explorer 402 Document Not Specified 7.8 磅 Normal 0 Specifications: Brand: Eachine Item Name: Screws sets for Lizard 105s Package include:4 x M2*10 Nylon screw 4 x M2*D4*H4 Nylon column 4 x M2*5+5 Nylon hexagonal column 4 x M2*8+5 Nylon hexagonal column 4x M2 Nylon Nut ...

Eachine Lizard 105S FPV Racing Drone Spare Part Motor Mount Holder Specifications: Brand: Eachine Item name: Motor mount holder Usage for Eachine Lizard 105 S Package include:4 x Motor mount holder ...
