Eachine Novice-II1-2S FPV Racing Drone RTFFly more w/ WT8 2.4G Transmitter 5.8 Ghz 40CH VR009 Goggles Specifications: Brand Name: Eachine Item Name: Novice-II 1-2S RTFFly more Wheelbase: 120mm
Size: 100mm*100mm*40mm Weight: 50g (without battery)
Features: Nano X F4 pro flight controller Powerful & smoothly Led Strip ready Built-in Buzzer New design 1103 KV8500 motors Camera Angle adjustable VTX power switchable 25mw~200mw Smartaudio ready, change VTX bands, powers, channels via OSDReady to fly Compatible both for 1s-2s Lipo/LIHVSpare parts specifications: Motor Mode: EX1103KV options: KV8500 Configu-ration:9N12 P Stator Diamter:11mm Stator Length:3mm Shaft Diameter: 1.5mm Motor Dimension (Dia.* Len):13.5mm*16mm Weight (g):3.8g Flight controller MCU:STM32F411CEU6 (100MHZ, 512K FLASH) Sensor: MPU-6000 (SPI connection) Board

Size: 28.5 * 28.5MMPower supply: 1-2S battery input (DC 3.5-8.7V) Built-in 5A (each) Blheli_S 4in 1 ESC Dshot 600 ready Built-in Frsky D8 SPI receiver Built-in Betaflight OSD (SPI Control) Built-in Current meter Max 28 A Current meter scale set to 1175 Built-in 5V 1A BECBuilt-in voltage detection Onboard 4in 1 ESCMCU upgraded to EFM8BB21 Power supply: 2-4S Li Po/ Li Po HV (7v/17v) Current: 5A continuous peak 6A (5 seconds) Support BLHeli Suite programmable Factory firmware: S_H_50_REV16_7.HEXDefault protocol: DSHOT600 Internal Frsky NON-EU receiver Version SPI BUS receiver Frsky D8 Compatible Non EU transmitter both D8 mode Channels: 8ch Failsafe support No ground interference (Transmitter & receiver 1 m from th



...

Eachine Novice-II 120mm 2.5 Inch FPV Racing Drone Spare Part Frame Kit Specification: Brand Name: Eachine Model Name: Novice-II Frame Kit Wheelbase: 120mm
Materials: Carbon & PCBWeight: 19.4gram Package Included:1 x Frame Kit 1111 Microsoft Internet Explorer 402 Document Not Specified 7.8 磅 Normal 0
...

Eachine Novice-II FPV Racing Drone Spare Part 25~200mw Switchable 40CH VTX 3.3-5.5V FPV Transmitter Specification: Brand name: Eachine Item name: 25~200mw 40CH VTX FPV Transmitter Output power: 25~200mw switchable Frequency: 40CHInput voltage: 3.3V 5.5 V Current consumption: 300m A (type) Antenna: RG178 antenna U.FL interface Frequency: 5.8 G Hz 5bands 40 channels With Raceband Smartaudio ready Weight: 2g without antenna The new version was added GNDpad & Buzz+ (+5v output)pad which can easily solder to the Eachine LEDBuzzer module of Novice-IIPackage Included:1 x 25~200mw 40CH VTX FPV Transmitter ...

Eachine Novice-II FPV Racing Drone Spare Part 3.8V 460m Ah 50C/100C 1S Lipo Battery 60*18*7mm PH2.0 Output Specification: Brand: Eachine Capacity:460m Ah Voltage:3.8v Continuous Discharge Rate: 50 C Instantaneous discharge rate: 100 C Connector: PH2.0
Size: 60mmx 18mmx 7mm Weight: 13.6g Package Included:1 x 3.8V 460m Ah 50C/100C 1S Lipo Battery 1111 Microsoft Internet Explorer 402 Document Not Specified 7.8 磅 Normal 0
...

Eachine Novice-II FPV Racing Drone Spare Part 3K Carbon Fiber 2.5mm Bottom Plate Specification: Brand name: Eachine Item name: Carbon bottom Plate
Material: 3K Carbon Fiber Thickness: 2.5mm Weight: 9.2 g Usage: for Eachine Novice-IIPackage included:1 x Carbon bottom Plate
...

Eachine Novice-II FPV Racing Drone Spare Part Handbag Bag with Sponge Specification: Brand name: Eachine Item name: Handbag Suitable for Eachine Novice-IIPackage Included:1 x Handbag 1111 Microsoft Internet Explorer 402 Document Not Specified 7.8 磅 Normal 0 ...

Eachine Novice-II FPV Racing Drone Spare Part LED Strip Board Buzzer Module Specification: Brand name: Eachine Product Name: LED Strip board Buzzer module Used for Eachine Novice-IIWeight: 3.3g Package Included:1 x LED Strip board Buzzer module ...

Eachine Novice-II FPV Racing Drone Spare Part NC1103 8500KV 2-3S 1.5mm Shaft Toothpick Brushless Motor Specifications: Brand Name: Eachine Mode:NC1103KV option: 8500KVConfigu-ration:9N12 P Stator Diamter:11mm Stator Length:3mm Shaft Diameter: 1.5mm Motor Dimension (Dia.* Len):13.5mm*15.5mm Weight (g):3.8g No.of Cells (Lipo):2-3S
Features: High efficiency & smooth Dual bearing design & more balance Better for Toothpick building Used for Eachine NOVICE-IIPackage Included:1 x NC1103 8500KV Brushless Motor
...

Eachine Novice-II Spare Part Turbo EOS2 V2 Customized Version 1200 TVL NTSC 4:3 1/3 CMOS FPV Camera Specificaton: Brand name: Eachine Model Turbo EOS2V2 Image Sensor 1/3CMOSSensor Horizontal Resolution 1200 TVLTVSystem NTSCIMAGE4:3 Synchronization Internal Electronic Shutter PAL: 1/50~100, 000; NTSC: 1/60~100, 000S/N Ratio 52d B (AGC OFF) Video Output CVBSLens 2.1mm Min. Illumination 0.001 Lux@F1.2 Auto Gain Control YESBLCYESWDRGlobal WDRDNR2 DNRDimensions 14mm*14mm*16mm Wide Power Input DC 3.3-6 V Work Temperature-20℃~+60℃ Work Humidity 20%~80% Weight 3.5g (N.W.) Package Included:1 x EOS2 V2 Customized Version Camera ...

Eachine Novice-III 135mm 2-3S 3 Inch FPV Racing Drone RTFFly more w/ 5.8G 40CH EV800 Goggles 2.4G ER8 Transmitter User Manual, Download Specifications: Brand Name: Eachine Item Name: Novice-III 2-3S Toothpick RTFFly more Wheelbase: 135mm
Size: 115mm*110mm*40mm Weight: 62g (without battery)
Features: New toothpick F4 flight controller Internal SPI Frsky D8/D16 receiver (Dual antenna & with PA) Powerful & smoothlyandlong flight time (about 8~10 Mins) Led Strip ready Built-in Buzzer ready New design 1203 KV5500 motors Camera Angle adjustable VTX power switchable 25mw~400mw Smartaudio ready, change VTX bands, powers, channels via OSD720P DVR ready (Analog 1280*720) Real Ready to fly Compatible both for 2s-3s Lipo/LIHV1111 Microsoft Internet Explorer 402 Document Not Specified 7.8 磅 Normal 0 Spare parts specifications: Motor Mode: EX1203KV options: KV5500 Configu-ration:9N12 P Stator Diamter:15mm Stator Length:3mm Shaft Diameter: Φ1.5mm Motor Dimension (Dia.* Len):Φ15mm*15mm Weight (g):4.5g Flight controller MCU:STM32F411CEU6 (100MHZ, 512K FLASH) Sensor: MPU-6000 (SPI connection) Board

Size: 28.5 * 28.5MMPower supply: 2-4S battery input (DC 8V-17V) Built-in 10A (each) Blheli_S 4in 1 ESC Dshot 600 ready Built-in Frsky D8/D16 SPI receiver Built-in 2.4G Power Amplification Built-in Betaflight OSD (SPI Control) Built-in Current meter Max 70 A Built-in 5V 1.5A BECBuilt-in voltage detection Onboard 4in 1 ESCMCU upgraded to EFM8BB21 Power supply: 2-4S Li Po/ Li Po HV (7v/17v) Current: 10A continuous peak 12A (5 seconds) Support BLHeli Suite progr



...
