Eachine Novice-II FPV Racing Drone Spare Part Handbag Bag with Sponge Specification: Brand name: Eachine Item name: Handbag Suitable for Eachine Novice-IIPackage Included:1 x Handbag 1111 Microsoft Internet Explorer 402 Document Not Specified 7.8 磅 Normal 0 ...

Eachine Novice-II FPV Racing Drone Spare Part LED Strip Board Buzzer Module Specification: Brand name: Eachine Product Name: LED Strip board Buzzer module Used for Eachine Novice-IIWeight: 3.3g Package Included:1 x LED Strip board Buzzer module ...

Eachine Novice-II FPV Racing Drone Spare Part NC1103 8500KV 2-3S 1.5mm Shaft Toothpick Brushless Motor Specifications: Brand Name: Eachine Mode:NC1103KV option: 8500KVConfigu-ration:9N12 P Stator Diamter:11mm Stator Length:3mm Shaft Diameter: 1.5mm Motor Dimension (Dia.* Len):13.5mm*15.5mm Weight (g):3.8g No.of Cells (Lipo):2-3S
Features: High efficiency & smooth Dual bearing design & more balance Better for Toothpick building Used for Eachine NOVICE-IIPackage Included:1 x NC1103 8500KV Brushless Motor
...

Eachine Novice-II Spare Part Turbo EOS2 V2 Customized Version 1200 TVL NTSC 4:3 1/3 CMOS FPV Camera Specificaton: Brand name: Eachine Model Turbo EOS2V2 Image Sensor 1/3CMOSSensor Horizontal Resolution 1200 TVLTVSystem NTSCIMAGE4:3 Synchronization Internal Electronic Shutter PAL: 1/50~100, 000; NTSC: 1/60~100, 000S/N Ratio 52d B (AGC OFF) Video Output CVBSLens 2.1mm Min. Illumination 0.001 Lux@F1.2 Auto Gain Control YESBLCYESWDRGlobal WDRDNR2 DNRDimensions 14mm*14mm*16mm Wide Power Input DC 3.3-6 V Work Temperature-20℃~+60℃ Work Humidity 20%~80% Weight 3.5g (N.W.) Package Included:1 x EOS2 V2 Customized Version Camera ...

Eachine Novice-III 135mm 2-3S 3 Inch FPV Racing Drone RTFFly more w/ 5.8G 40CH EV800 Goggles 2.4G ER8 Transmitter User Manual, Download Specifications: Brand Name: Eachine Item Name: Novice-III 2-3S Toothpick RTFFly more Wheelbase: 135mm
Size: 115mm*110mm*40mm Weight: 62g (without battery)
Features: New toothpick F4 flight controller Internal SPI Frsky D8/D16 receiver (Dual antenna & with PA) Powerful & smoothlyandlong flight time (about 8~10 Mins) Led Strip ready Built-in Buzzer ready New design 1203 KV5500 motors Camera Angle adjustable VTX power switchable 25mw~400mw Smartaudio ready, change VTX bands, powers, channels via OSD720P DVR ready (Analog 1280*720) Real Ready to fly Compatible both for 2s-3s Lipo/LIHV1111 Microsoft Internet Explorer 402 Document Not Specified 7.8 磅 Normal 0 Spare parts specifications: Motor Mode: EX1203KV options: KV5500 Configu-ration:9N12 P Stator Diamter:15mm Stator Length:3mm Shaft Diameter: Φ1.5mm Motor Dimension (Dia.* Len):Φ15mm*15mm Weight (g):4.5g Flight controller MCU:STM32F411CEU6 (100MHZ, 512K FLASH) Sensor: MPU-6000 (SPI connection) Board

Size: 28.5 * 28.5MMPower supply: 2-4S battery input (DC 8V-17V) Built-in 10A (each) Blheli_S 4in 1 ESC Dshot 600 ready Built-in Frsky D8/D16 SPI receiver Built-in 2.4G Power Amplification Built-in Betaflight OSD (SPI Control) Built-in Current meter Max 70 A Built-in 5V 1.5A BECBuilt-in voltage detection Onboard 4in 1 ESCMCU upgraded to EFM8BB21 Power supply: 2-4S Li Po/ Li Po HV (7v/17v) Current: 10A continuous peak 12A (5 seconds) Support BLHeli Suite progr



...

Eachine Novice-III 135mm 2-3S 3 Inch FPV Racing Drone Spare Part 3K Carbon Fiber 3mm Bottom Plate Specification: Brand: Eachine Item name: Carbon bottom Plate
Material: 3K Carbon Fiber Thickness: 3mm Weight: 11.8 g Usage: for Eachine Novice-IIIPackage included:1 x Carbon bottom Plate
...

Eachine Novice-III 135mm 2-3S 3 Inch FPV Racing Drone Spare Part LED Strip Board Buzzer Mudule Specification: Bran Name: Eachine Product Name: LED Strip board Buzzer module Used for Eachine Novice-II & Novice-IIIWeight: 3.3g Package Included:1 x LED Strip board Buzzer module ...

Eachine Novice-III 135mm 2-3S 3 Inch FPV Racing Drone Spare Part NC1203 1203 5500KV 2-4S Brushless Motor Note: Long model with 60mm cable wire. Short model with 50mm cable wire. Specification: Brand Name: Eachine Mode: NC1203KV option: KV5500 Configu-ration:9N12 P Stator Diamter:12mm Stator Length:3mm Shaft Diameter:1.5mm Motor Dimension (Dia.* Len):15mm*15mm Weight (g):4.7g No.of Cells (Lipo): KV5500 support 2-4s Model No Load Propeller Voltage (v) Currents (A) Thrust (g) Power (W) Efficiency (g/W) Throttle NC1203-55000.14A 11310RPM Gemfan 3025 76mm bi-blade 11.1156.311.15.072 1439 11.1291.622.24.126 1593 11.13120.533.33.619 1712 11.14148.744.43.349 1837 11.15169.555.53.054 1920 11.15.8183.664.382.852 2200 1111 Microsoft Internet Explorer 402 Document Not Specified 7.8 磅 Normal 0 Package Included:1 x NC1203 5500KV Brushless Motor ...

Eachine Novice-III 135mm 2-3S 3 Inch FPV Racing Drone Spare Part Screws Damping Ball Specification: Brand Name: Eachine Used for Eachine NOVICE-III Flight stack Package included:4 x Damping ball 4 x M2 x 16 screws 4 x M2 x 6 screw 4 x M1.4 x 5 screw 4 x 2mm height M2 nylon nut 8 x 1mm height M2 nylon nut ...

Eachine Novice-III 135mm 2-3S FPV Racing Drone Spare Part 5.8G 40CH Pegasus 25~400m W VTX DVR 3.3V-5.5 V Specifications: Brand Name: Eachine Output power: 25~400mw switchable Frequency: 40CHInput voltage: 3.3V 5.5 V Current consumption: 250~400m A (type) Antenna: RG178 antenna U.FL interface Frequency: 5.8 G Hz 5bands 40 channels With Raceband Smartaudio ready Weight: 3.4g without antenna Video Output

Size: VGA (640x 480) Video Output format: NTSCRecord video size: 1280x 720 @25FPSTF Card support: Max.32 G Interface: JST SH1.0 3pin for Camera JST SH1.0 5pin for Connect with F3/F4 Flight controller Compress Format: AVI
Features: Short touch the button to Start/ Stop Video recorder Best for 20x 20mm flight stack Built-in DVR (Video size 1280x 720) Auto start when power on Note: Auto-save when Power off is not support, please remember to press the stop button after landing Package included:1 x Pegasus VTX1 x JST SH1.0 3 Pin wire for camera 1 x JST SH1.0 5 Pin wire for flight controller 1111 Microsoft Internet Explorer 402 Document Not Specified 7.8 磅 Normal 0


...
