Eachine Red Devil FPV Racing Drone Spare Part 2mm Carbon Fiber Bottom Plate Specification: Brand name: Eachine Item name:2mm Carbon Fiber Bottom Plate Wheelbase: 105mm Suitable for Red Devil 85mm Frame Kit / sailfly-XWeight: 6.2g Package Included:1 x 2mm Carbon Fiber Bottom Plate ...

Eachine Red Devil 105mm FPV Racing Drone Spare Part 11.1V 300m Ah 30/60C Lipo Battery Specification: Brand Name: Eachine Capacity:300m Ah Voltage:11.4v Continuous Discharge Rate: 30 C Instantaneous discharge rate: 60 C Connector: XT30
Size: 65mmx 18mmx 11mm Weight: 25.7g Package Included:1 x 11.1V 300m Ah 30C/60C Lipo Battery
...

Specifiactions: Mode: 1102 8700KVConfigu-ration:9N12 P Stator Diamter:11mm Stator Length:2mm Shaft Diameter: 1.5mm Motor Dimension (Dia.* Len):13.5mm*16mm Weight (g):2.8g No.of Cells (Lipo):2S-3 S Suitable for Reddevil Note: Clockwire rotation is red wire. Counter clockwise rotation is black wire. Recommend Parts ( Not included):M2*6 12.9 Screw for 2 Inch propeller Package Included:1 x 1102 8700KV Brushless Motor ...

Eachine Red Devil 105mm FPV Racing Drone Spare Part 3D Printed Battery Mount Specification: Brand name: Eachine Item name: 3D Printed Battery Mount
Materials: PCWeight: 0.5gram Suitable for Eachine Red Devil 105mm FPV Racing Drone Package Included:1 x 3D Printed Battery Mount
...

Eachine Red Devil 105mm FPV Racing Drone Spare Part CADDX EOS2 16:9 FPV Camera Description Model Turbo EOS2 Image Sensor 1/3CMOSSensor Horizontal Resolution 1200 TVLTVSystem NTSC /PALoption IMAGE16:9 Synchronization Internal Electronic Shutter PAL: 1/50~100, 000; NTSC: 1/60~100, 000S/N Ratio 52d B (AGC OFF) Video Output CVBSLens 2.1mm Min. Illumination 0.001 Lux@F1.2 Auto Gain Control YESBLCYESWDRGlobal WDRDNR2 DNRDimensions 14mm*14mm*16mm Wide Power Input DC 3.3-6 V Work Temperature-20℃~+60℃ Work Humidity 20%~80% Weight 3.5g (N.W.) Connector is SH1.0 3PIN, compatible Reddevil, Trashcan, whoop_vtx, VTX Nano Package Included:1 x FPV Camera ...

Eachine Red Devil 105mm FPV Racing Drone Spare Part Rubber Damping Ball Nylon Screws Specification: Brand name:  Eachine Item name:  Rubber Damping Ball Nylon Screws Suitable for  Eachine Red Devil 105mm FPV Racing Drone Package Include:3 x D4*L7 Long rubber damping ball 1 x D4*L4 Short rubber damping ball (front)4 x M2*18 Nylon screws 11 x M2 Nylon nut  ...

Eachine Red Devil 105mm FPV Racing Drone Spare Part XT30 Plug Pigtail Power Wire with 100F Capacitor Specification: Brand name: Eachine Item name:XT30 Plug Pigtail Power Wire with 100F Capacitor Suitable for Eachine Red Devil 105mm FPV Racing Drone Package Included:1 x XT30 Plug Pigtail Power Wire with 100F Capacitor ...

Eachine Red Devil 105mm Wheelbase FPV Racing Frame Kit for RC Drone Specification: Brand name: Eachine Item name: Frame Kit Package include:1 x 2mm Carbonfiber bottom plate 1 x EOS2 compatible canopy 1 x Battery holder 4 x Rubber damping balls 4 x M2*18 Nylon screws 11 x M2 Nut 12 x M1.4*4 screws ...

Eachine Red Devil V2 105mm 2-3S FPV Racing Drone Whoop Crazybee F4 PRO Caddx EOS2 5.8G 25~200m W Nano VTXNote: Thepropellerhasbeenupgradedto H Qprop 65mmtosolvetheproblemofshakingduringflight. Specifications: Brand Name: Eachine Item Name: Red Devil V2 2-3S Micro FPV racingdrone Wheelbase: 105mm
Size: 95mm*95mm*50mm (without propellers) Weight: 37.4g (without battery) Weight:63.2g (with Original 3s 300mah Lipo battery ) Spare parts specifications: Motor Mode: EX1102KV8700 Configu-ration:9N12 P Stator Diamter:11mm Stator Length:2mm Shaft Diameter:1.5mm Motor Dimension (Dia.* Len):13.5mm*16mm Weight (g):2.8g No.of Cells (Lipo):2S-3 S Flight controller (Frsky version) CRAZYBEE F4FR PRO V2.1 Firmware target: Crazybee F4FR (Flysky version) CRAZYBEE F4FS PRO V2.1 Firmware target: Crazybee F4FS (DSM2/DSMX version) CRAZYBEE F4DX PRO V2.1 Firmware target: Crazybee F4DX (No RX version) CRAZYBEE F4 PRO V2.1 Firmware target: Crazybee F4DXMCU:STM32F411CEU6 (100MHZ, 512K FLASH) Sensor: MPU-6000 (SPI connection) Board

Size: 28.5 * 28.5MMPower supply: 2-3 Sbattery input (DC 7.4-13V) Built-in 5A (each) Blheli_S 4in 1 ESC Dshot 600 ready Frsky version Built-in SPI Frsky receiver with telemetry (D8/D16 switchable) Flysky version Built-in SPIFlysky receiver with telemetry (AFHDS/AFHDS2 Aswitchable)DSM2/X Version built-in Serial-based DSM2/DSMX compatible satellite receiver No RX version need to add external Receiver Built-in Betaflight OSD (SPI Control) Built-in Current meter Max 28 A Current meter scale set to 1175 Built-in 5V 1A BECwith LC filter Built-in


...

Eachine Revenger 55 Racing Drone Spare Parts Flight Controller & ESC Fixing Mount Specification: Brand Name: Eachine Item Name: Flight controller & ESC fixing mount Weight: 0.5g/pcs Package Included:2x Flight controller & ESC fixing mount 4x Screws 4x Nut ...
