Eachine LAL5 228mm 4K FPV Racing Drone Spare Part 5mm Arm Plate for Frame Kit Specification: Brand name: Eachine Item name: 5mm arm plate Meterail: Carbon fiber Suitable for Eachine LAL5 228mm 4K FPV Racing Drone Weight: 11g Package Included:1 x 5mm arm plate ...

Eachine LAL5 228mm 4K FPV Racing Drone Spare Part Cable Wire Set Specification: Brand name: Eachine Item name: Cable Wire Set Suitable for Eachine LAL5 228mm 4K FPV Racing Drone Package Included:1 x Cable Wire Set ...

Eachine LAL5 228mm 4K FPV Racing Drone Spare Part Frame 2mm Upper Plate Specification: Brand name: Eachine Item name: 2mm Upper Plate Suitable for Eachine LAL5 228mm 4K FPV Racing Drone Package Included:1 x 2mm Upper Plate ...

Eachine LAL5 228mm 4K FPV Racing Drone Spare Part Frame Kit 2mm Bottom Plate Specification: Brand name: Eachine Item name: 2mm Bottom Plate Suitable for Eachine LAL5 228mm 4K FPV Racing Drone Package Included:1 x 2mm Bottom Plate ...

Eachine LAL5 228mm 4K FPV Racing Drone Spare Part Frame Screws Flight Controller Screw Specification: Brand name: Eachine Item name: Frame Screws Flight Controller Screw Suitable for Eachine LAL5 228mm 4K FPV Racing Drone Package Included:1 x Frame Screws Flight Controller Screw ...

Eachine LAL5 228mm 4K FPV Racing Drone Spare Part TX805 5.8G 40CH FPV Transmitter VTX 7V~24V Smart Audio Specification: Brand name: Eachine Item name:FPV Transmitter VTXFrequency:5.8 G Channels:40CHInput voltage: 7V~24V5V camera supply: 120m A (MAX)----25m W@12V5V camera supply: 200m A (MAX)----200m W@12V5V camera supply: 300m A (MAX)----600m W@12V5V camera supply: 350m A (MAX)----800m W@12 V Extra

Features: Smart audio Power supply: 5V output for Camera Output power: 25m W/200m W/600m W/800m W switchable Antenna connector: MMCXCable connector: Solder pads Dimensions: 36mm*22mm*5mm, 30.5 stackable hole Weight: 8g (excluding antenna) Package Included:1 x FPV Transmitter

...

Eachine LAL5 228mm 4K FPV Racing Drone Spare Part VTX Antenna Fixing Mount Seat Specification: Brand name: Eachine Item name: VTX Antenna Fixing Mount Seat Suitable for Eachine LAL5 228mm 4K FPV Racing Drone Package Included:1 x VTX Antenna Fixing Mount Seat ...

Eachine LAL5.1 225mm 5.1 Inch 4S PNP F405 Bluetooth FC Caddx Tarsier V2 Cam 2507 2600KV 50A Blheli_32 3-6S 5.8 Ghz 25-800m W VTX Specifications: Brand Name: Eachine Item Name: LAL5 225mm 5.1 Inch 4K 4S FPV Racing Drone Wheelbase: 225mm Weight: 411.8g (without battery) Package

Size: 270x 270x 160mm Package weight: 1034.7g Frame Wheelbase: 225mm Arm thickness: 5mm X plate: 2mm Bottom plate: 2mm Upper plate: 2mm Motor Mode: 2507KV: 2600 Idle current (IO/10V): 2.45 A No.of Cells (Lipo): 3-5 S Peakcurrent: 40 A Max. power: 672 W Max. thrust: 1187g (4s/5) Configu-ration:12N14 P Internal Resistance:0.0321 Stator diameter: 25mm Stator thickness: 7mm
Height: 19.5mm
Width: 31mm Shaft diameter: 5mm Motor mount hole

Size: M3 Recommend propeller: 5-6 Inch Weight: 47g ESC50A 3-6S DSHOT1200 4 IN 1 ESCContinue current: 50 A Burst current: 60A (10s) Input voltage: 3-6SBEC: NO Current sensor: YESMain control chip: STM32F051 Mos chip: TPH1R403 Firmware: Blheli_32 Support DSHOT 150/300/600/1200/MULTISHOT/PWM/ONESHOTMOS:5 * 6 Galvanometer: None Weight: 13.5g Installation hole: 30.5x 30.5mm/3 Dimension: 49 *37mm Flight Controller EACHINE Customized LAL-F405 Bluetooth Flight Controller STM32F405 Chip MPU: MPU6000 (via SPI) Input voltage: support 2-6S Lipo input Onboard Bluetooth module, support APP configuration via smartphone Firmware: MATEKF405 Onboard German Bosch BMP280 high precision barometer Flight control onboard OSD chip, support DMA mode (use F4 MCU to control OSD), you can use Beta Flight to adjust soft Piece





...

Eachine LAL5.1 225mm 4K 5.1 Inch 4S FPV Racing Drone Spare Part 2507 2600KV 3-5S Brushless Motor Specification: Brand name: Eachine Item name:2507 2600KV 3-5S Brushless Motor Mode: 2507KV: 2600 Idle current (IO/10V): 2.45 A No.of Cells (Lipo): 3-5 S Peakcurrent: 40 A Max. power: 672 W Max. thrust: 1187g (4s/5) Configu-ration:12N14 P Internal Resistance:0.0321 Stator diameter: 25mm Stator thickness: 7mm
Height: 19.5mm
Width: 31mm Shaft diameter: 5mm Motor mount hole

Size: M3 Recommend propeller: 5-6 Inch Weight: 47g Package Included:1 x 2507 2600KV Brushless Motor



...

Eachine LAL5.1 225mm 5.1 Inch 5mm Arm Carbon Fiber FPV Racing Frame Kit Specification: Brand name: Eachine Item name:LAL5.1 Frame Kit Wheelbase: 225mm Arm thickness: 5mm X plate: 2mm Bottom plate: 2mm Upper plate: 2mm Weight: 99.8g Package Included:1 x LAL5.1 Frame Kit 1 x Battery Strap ...
