Overview: Eachine NANO VTX is simulated 5.8G ISM band transmission with stable output power, long transmission distance & strong power filter. It can ensure that the image has no snowflake, no stripes under the maximum throttle situation. Meanwhile, Eachine NANO VTX has remote frequency point control of remote control OSD interface, does not interfere with fellows when powered on, and support 8 peoples above flying at the same time super function. Upgraded V2 Version With Microphone, Click Here Specifications: Brand Name: Eachine Item Name:NANO VTXOutput Power: PIT/25m W/100m W/200m W/400m W Switchable Control Mode: BFOSD Control (RX)/ Button BAT: 5 V Video System: NTSC/PALAntenna: IPEX
Size: 14MM*15MM*4MMWeight: 1.5g

Features:- 5.8 G Hz 48CH FPV transmitter- 5V input voltage- 25/100/200/400m W power switchable- Support OSD configuring via Betaflight flight controller Frequency Table (Mhz):FR/CHCH1 (○○○)CH2 (○○●)CH3 (○●○)CH4 (○●●)CH5 (●○○)CH6 (●○●)CH7 (●●○)CH8 (●●●) Frequency A (○○●)58655845582558055785576557455725 Frequency b (○●○)57335752577157905809582858475866 Frequency E (○●●)57055685566556455885590559255945 Frequency F (●○○)57405760578058005820584058605880 Frequency r (●○●)56585695573257695806584358805917 Frequency L (●●○)53625399543654735510554755845621 English Manual, Click Here Package Included:1x Eachine NANO VTX 5.8 G Hz 48CH 25/100/200/400m W Switchable FPV Transmitter 1x IPEX Antenna 1x User Manual


...

Eachine NC0802 0802 19000KV 1S Brushless Motor Part for UZ65 Whoop FPV Racing Drone Specification: Brand name: Eachine Item name: NC0802 1-2S brushless motor KV: 19000kv Shaft Diameter: 1.0mm Configuration: 9N12 P Stator Diameter: 8mm Stator Length: 2mm Motor Dimension (Dia.* Len): Φ10.5mm*14.9mm Terminals: JST1.25mm No.of Cells (Lipo): 1 S Wire length (include connector): 40mm Weight: 1.8g Package Included:1 x NC0802 1-2S Brushless Motor ...

null Eachine NC1204 1204 5000KV 3-4S Brushless Motor for Viswhoop Whoop Drone 60mm Wire JST1.25 Plug Specification: Brand Name: Eachine Mode: NC1204KV option: KV5000 Configu-ration:9N12 P Stator Diamter:12mm Stator Length:4mm Shaft Diameter:Φ1.5mm No.of Cells (Lipo):support 3-4s Motor Dimension (Dia.* Len):Φ15mm*16.5mm Weight (g):5.5g Package Included:1 x NC1204 1204 5000KV 3-4S Brushless Motor ...

Note: The goggles of CN warehouse has been upgraded to 5.8 Ghz 40CH VR009 Goggles on May 27th. Other warehouse is VR005 Goggles. Novice-I biginner PID & Rate CLI comm&. Please click here to download & setting. Add external SBUS IBUS DSM2 DSMX Receiver for Novice-I FC, Click here. Specifications: Brand Name: Eachine Item Name: Novice-I75mm 1-2S brushless whoop Drone RTFFly more Wheelbase: 75mm
Size: 98mm*98mm*48mm Weight: 33g (without battery)
Features: Nano X F4 pro flight controller Powerful & smoothly Betaflight OSD support, easy to get RSSI, Voltage, current from your goggles Camera Angle adjustable VTX power switchable 25mw~200mw Smartaudio ready, change VTX bands, powers, channels via OSDReady to fly Compatible both for 1s-2s Lipo/LIHVSpare parts specifications: Motor Mode: EX1102KV options: KV13500 Configu-ration:9N12 P Stator Diamter:11mm Stator Length:2mm Shaft Diameter: Φ1.5mm Motor Dimension (Dia.* Len):Φ13.5mm*16mm Weight (g):2.8g Flight controller MCU:STM32F411CEU6 (100MHZ, 512K FLASH) Sensor: MPU-6000 (SPI connection) Board

Size: 28.5 * 28.5MMPower supply: 1-2S battery input (DC 3.5-8.7V) Built-in 5A (each) Blheli_S 4in 1 ESC Dshot 600 ready Built-in Frsky D8 SPI receiver Built-in Betaflight OSD (SPI Control) Built-in Current meter Max 28 A Current meter scale set to 1175 Built-in 5V 1A BECBuilt-in voltage detection Onboard 4in 1 ESCMCU upgraded to EFM8BB21 Power supply: 2-4S Li Po/ Li Po HV (7v/17v) Current: 5A continuous peak 6A (5 seconds) Support BLHeli Suite programmable Factory firmware: S_H_50_REV16_7



...

Eachine Novice-I 75mm FPV Racing Dorne Spare Part WT8 2.4 Ghz Transmitter Specification: Brand Name: Eachine Model: WT8 Mode: Mode 2 (Left hand throttle) Frequency:2.4 Ghz Frequency Hopping: Latest FHSS (64 points, 3.6ms) Channels: 8channels Resolution: 4096 Transmission: 100mw (20dbm) Distance: 1000m (depends on actual situation) Working Voltage:4.2-6v (AAA1.5v*4) Working current: 100-150m A
Size:162*110*62MM
Colour: Black Package Included:1 x WT8 Radio Transmitter

...

Eachine Novice-I 75mm FPV Racing Drone Spare Part Canopy Camera Mount Specification: Brand Name: Eachine
Colour: Transparent
...

Eachine Novice-I 75mm FPV Racing Drone Spare Part Frame Kit Specification: Brand name: Eachine Item name: Frame Kit Suitable for NOVICE-I75mm FPV Racing Drone Weight: 5.6g Package Included:1 x Frame Kit ...

Eachine Novice-I 75mm FPV Racing Drone Spare Part Handbag Case Bag Specification: Brand name: Eachine Item name: Handbag Suitable for Eachine Novice-I 75mm FPV Racing Drone Package Included:1 x Handbag ...

Eachine Novice-I 75mm FPV Racing Drone Spare Part Nano-X F4 Pro AIO Flight Controller 1-2S OSD Built-in 5A Blheli_S 4in 1 ESC Frsky D8 SPI Receiver Specification: Flight Controller MCU:STM32F411CEU6 (100MHZ, 512K FLASH) Sensor: MPU-6000 (SPI connection) Board

Size: 28.5 * 28.5MMPower supply: 1-2S battery input (DC 3.5-8.7V) Built-in 5A (each) Blheli_S 4in 1 ESC Dshot 600 ready Built-in Frsky D8 SPI receiver Built-in Betaflight OSD (SPI Control) Built-in Current meter Max 28 A Current meter scale set to 1175 Built-in 5V 1A BECBuilt-in voltage detection 1111 Microsoft Internet Explorer 402 Document Not Specified 7.8 磅 Normal 0 Brushless ESCMCU upgraded to EFM8BB21 Power supply: 2-4S Li Po/ Li Po HV (7v/17v) Current: 5A continuous peak 6A (5 seconds) Support BLHeli Suite programmable Factory firmware: S_H_50_REV16_7.HEXDefault protocol: DSHOT600 Receiver SPI BUS receiver Frsky D8 Compatible Non EU transmitter both D8 mode Channels: 8ch Failsafe support No ground interference (Transmitter & receiver 1 m from the ground): 200m Package Included:1 x Nano-X F4 Pro AIO Board

...

Eachine Novice-I 75mm FPV Racing Drone Spare Part NC1102 1102 13500KV 1-2S Brushless Motor Specifications: Brand Name: Eachine Mode: NC1102 13500KVConfigu-ration:9N12 P Stator Diamter:11mm Stator Length:2mm Shaft Diameter: 1.5mm No.of Cells (Lipo):2 S Suitable for NOVICE-IMotor Dimension (Dia.* Len):13.5mm*16mm Weight (g):2.9g Package Included:1 x NC1102 13500KV Brushless Motor ...
