Eachine Tyro 69 105mm F4 OSD 2.5 Inch 2-3S DIY FPV Racing Drone PNP w/ Caddx 1200TVL Camera Click here to buy Spare Parts. Notice:1. This is the DIY version that comes unassembled.2. Comes without battery, charger, receiver or radio transmitter. Specification: (Manual) Brand Name: Eachine Model: Tyro 69 Item Name:2.5 Inch DIY FPV Racing Drone Version: PNP (Without Receiver, Battery & Radio Transmitter) Drone Wheelbase: 105mm Arm Plate Thickness: 2mm Max. Propeller: 2.5 Inch
Material: 3K Carbon Fiber 3D Printed TPU Parts Weight: 47.9g (without battery) Eachine F411 OSD Flight Controller Main control chip: STM32F411IMU: MPU6000 Integrated Betaflight OSDFirmware: Matek F411SBUS/ IBUS/ DSMX / UART Shared: UART1-RXBEC: 5V 2AWS2812 Led Strip: Yes Beeper: Yes Mounting Hole: 20x 20mm- Supportbetaflight/ cleanflight/ inav firmware-Plugs connector / Soldering Pads are Optional for all connector Port Eachine 20A BL_S 4 In 1 ESCMCU:48 M Hz EFM8BB21F16 G Input Voltage: 2-6 S Con. Current: 20 A Burst Current: 25A (10S)BEC: NO
Size:28.7x 30.7mm Mounting Hole: 20x 20mm Weight: 24g Support DShot 150/300/600, PWM, One Shot 125, One Shot 42, Multi Shot (DShot 600 in default out from factory) Eachine 1104 8600KV 2-3S Motor KV: 8600KVLipo cell: 2-3 S Weight: 4.3g
Colour: Orange Max. Con. Current: 13 A Max. Con. Power: 144 W Configu-ration: 9N/12 P Motor Resistance: 137m Stator Diameter: 11mm Stator Thickness: 4mm Motor Diameter: 13.8mm Motor Body Length: 11.5mm Overall Shaft Length: 17mm Bolt Holes Spacing: 9mm Bolt Thread: M265mm 2-Blade Propeller Item N


...

Eachine Tyro 69 Spare Part 105mm Wheelbase 2mm Thickness Bottom Plate for RC Drone Specification: Brand Name: Eachine Item Name:105mm Wheelbase 2mm Thickness Bottom Plate Wheelbase: 105mm Plate Thickness: 2mm
Material: Carbon Fiber Applciation: Original Part for Eachine Tyro 69 FPV Racing Drone Packaging Included:1x Bottom Plate
...

Eachine Tyro 69 Spare Part 1104 8600KV 2-3S Brushless Motor for RC Drone FPV Racing Specification: Brand Name: Eachine Item Name:1104 8600KV 2-3S Brushless Motor KV: 8600KVVersion: CW Screw Thread Input Voltage: 2-3S Lipo Configuration: 9N/12 P Stator Diameter: 11mm Stator

Height: 4mm Shaft Diameter: 1.5mm Weight: 4.3g Maximum Power: 144 W Installation Hole: M2 Installation Hole Spacing: 9mm Application: Original Parts for Eachine Tyro 69 DIY FPV Racing Drone Packiage Included:1x Eachine 1104 8600KV Motor 5x M2*4 Screw

...

Eachine Tyro 69 Spare Part 3D Printing TPU Camera Fixing Mount for RC Drone FPV Racing Specification: Brand Name: Eachine Item Name:3D Printing TPU Camera Fixing Mount
Material: TPU
Colour: Black Net Weight: 1.9g Applcation: Original Parts for Eachine Tyro 69 FPV Racing Drone Package Included:1x Camera Fixing Mount

...

Eachine Tyro 69 Spare Part 50mm XT30 Plug Connector Power Cable for RC Drone Specification: Brand Name: Eachine Item Name:XT30 Plug Connector Power Cable Length: 50mm Type: Male Head Applicaiton: Original Parts for Eachine Tyro 69 FPV Racing Drone Package Included:1x XT30 Connector Cable ...

Eachine Tyro 69 Spare Part Flight Controller ESC 6P Connection Cable Wire for RC Drone FPV Racing Specification: Brand Name: Eachine Item Name: 6P Cable for conencting fc to esc Applciation: Original Part for Eachine Tyro 69 FPV Racing Drone Package Included:1x 6P Conenction Cable ...

Eachine Tyro 69 Spare Part M2x 25 M2x 4 M2 Screw Anti-vibration Damping Ball Standoff for RC Drone Specification: Brand Name: Eachine Item Name:M2x 25 M2x 4 M2 Screw Anti-vibration Damping Ball Application: Original screws for Eachine Tyro 69 FPV Racing Drone Packaging Included:16x M2*4 screw 12x M2 isolation & shock absorber screw 4x M2 Nylon Nut 4x M2*25 screw ...

Eachine Tyro 69 Spare Part Upgrade V2 2g TPU Canopy Camera Mount for RC Drone Notice: ONLY include canopy. Other Parts are NOT Included. Specification: Brand Name: Eachine Item Name: Frame Canopy Camera Mount
Colour: Black Weight: 2.1g Application: Upgrade Part for Eachine Tyro 69 FPV Racing Drone Other recommend canopy: URUAV UR65 Canopy / Eachine US65/UK65 Canopy Package Included:1x Canopy
...

Eachine Tyro 79 140mm 3 Inch DIY Version FPV Racing Frame Kit 3mm Arm Carbon Fiber Description: Brand name: Eachine Item name: Tyro 79 140mm racing frame Wheel base: 140mm Frame arm thickness: 3mm Upper plate thickness: 1mm Side plate thickness: 1mm Frame kit

Material: 3K carbon fiber CNC 6065 aluminium Recommend parts (package doesnt include): Brushless motor: 1106/1606 Brushless ESC: 20 A Flight controller: F3 / F4 (mounting holes: 20*20mm) Battery: 2-3S 450-650mah Propeller: 3 inch Package included:1 x Tyro 79 140mm racing frame

...

Eachine Tyro 79 140mm 3 Inch DIY Version FPV Racing RC Drone w/ F4 OSD 20A BLHeli_S 700TVL Camera 5.8G 40CH 200m W VTXNote:1. This is the DIY version that comes unassembled.2. Comes without battery, charger, receiver or remote control. Upgrade in new VTX Module. More details, click here Item Specification 140mm Racing Frame Kit Wheel base: 140mm Frame arm thickness: 3mm Upper plate thickness: 1mm Side plate thickness: 1mm Frame kit

Material: 3K carbon fiber CNC 6065 aluminium 1607 2800KV 2-4S Brushless Motor KV: 2800KVLipo cell: 2-4 S Weight: 17.8g (
Includes: wires) Output shaft length: 14mm Maximum pull: signal 630g (4S 3030 4-blade propeller) Maximum power: 350 W Configu-ration: 9N/12 P Mounting holes distance: 12*12mm Mounting holes: M2 Bearing: NSKN52 Strong Nd Fe B Magnet Recommend propeller: 3 inch 4 IN 1 20A BLHeli_S ESCContinuous current: 20 A Peak current: 25A (10S)BEC output: no Input voltage: 2-4 S Main control chip: 48mhz EFM8BB2 Firmware upgrade: Supports Dshot 600/BLHeli_S/ Oneshot 125MOS: 3*3MOS type: vs 3610ae 30v 64a Customized F4 Flight Controller Main control chip: STM32F411 Sensor: ICM20602 6-axis Integrated OSDPPM/DSM/IBUS/UAR share: UART1-RXMounting holes distance: 20*20mm Weight: 24g PID circulation rate & refresh rate can up to 32k Hz Supports Betaflight/cleanflight/inav firmware 700TVL CMOS Camera Case

Size: 19mm*19mm Weight: 9.5g Total pixels: PAL: 1020H596V (0.61MP); NTSC: 1020H508V (0.52MP) Effective pixels: PAL: 976H582V (0.57MP); NTSC: 976H494V (0.48MP) Signal system: PAL/NTSC switchable Resolution r




...
