Eachine Tyro 79 140mm 3 Inch DIY Version RC Drone Spare Part 5.8G 40CH 25/100/200/300mw Switchable VTXDescription: Brand name: Eachine Item name: 5.8G 40CH25/100/200/300mw VTXSupports TBS Smart Audio Transmitting power:25/100/200/300mw switchable Channel: 40CHFull video format: NTSC/PALInput voltage: 7V~24 V Power dissipation: +12V/600MW
Size: 25206mm Weight: 3.2g (except antenna) With copper pipe mini antenna (ipex antenna) Make sure the antenna is installed at the output end before powering up to avoid damaging internal components. Usage: for tyro 79 140mm 3 inch DIY version RC drone Vtx Setting:1. Long Press Button 2S, entering into CH Setting Mode.2. Red Light flash 1 time, Green Light flash 1-8 time (CH1-CH8). At this time, a short press of the key CH plus 1 will flash corresponding number of times. CH1-8 cycle.3. Then, Long Press 2S again, entering into Band Setting Mode. Red Light flash 2 times, Green Light flash 1-5 time (A-B-E-FS-Race Band).4. Long Press 2S once again, entering into Power Setting Mode. Red Light flash 3 times, Green Light flash 1-4 times (Power 25m W- 100m W-200m W-300m W)5. Finally, Long Press 2S, Logout setting mode. Or it will logout automatically while no operation after 30S. Package included:1 x 5.8G 40CH 25/100/200/300m WVTX1 x antenna 1 x cable
...

Eachine Tyro 79 140mm 3 Inch DIY Version FPV Racing RC Drone Spare Part Customized F4 Flight Controller Integrated OSDDescription: Brand name: Eachine Item name: F4 Flight Controller Main control chip: STM32F411 Sensor: ICM20602 6-axis Integrated OSDPPM/DSM/IBUS/UAR share: UART1-RXMounting holes distance: 20*20mm Weight: 24g PID circulation rate & refresh rate can up to 32k Hz Supports Betaflight/cleanflight/inav firmware Package included:1 x F4 Flight Controller ...

Only US$129.99, buy best eachine tyro 79 pro diy 140mm f 4 aio 35a esc 4s 3 inch fpv racing drone pnp w/ 5.8g 400mw vtx runcam nano 2 fpv camera sale online store at wholesale price. ...

Only US$9.99, buy best eachine tyro 79 pro spare part 140mm 3 inch frame kit / replace arm aio bottom plate for rc drone fpv racing sale online store at wholesale price. ...

Only US$12.99, buy best eachine tyro 79 pro spare part 1607 2800kv 2-4s brushless motor for rc drone fpv racing sale online store at wholesale price. ...

Eachine Tyro 89 Spare Part 115mm Wheelbase 3mm Arm Thickness Bottom Plate for RC Drone Specification: Brand Name: Eachine Model: Tyro 89 Item Name:115mm Wheelbase 3mm Arm Thickness Bottom Plate Arm Plate Thickness: 3mm Wheelbase: 115mm
Material: 3K Carbon Fiber Weight: Around 9g Application: Original replace bottom plate for Eachine Tyro 89 FPV Racing Drone Package Included:1x Bottom Plate
...

Eachine Tyro 89 Spare Part 1204 6000KV 2-4S Motor for RC Drone FPV Racing Specification: Brand Name: Eachine Model: Tyro 89 Item Name:1204 6000KV 2-4S Brushless Motor Version: 30mm Cable with Connector / 60mm Cable without Connector (Optional) Quantity: One PCKV: 6000KVLipo cell: 2-4 S Weight: 6.2g Maximum power: 148 W Configu-ration: 9N/12 P Shaft Diameter: 1.5mm Motor Stator Diameter: 12mm Motor Stator Thickness: 4mm Mounting holes distance: 9*9mm Mounting holes: M2 Weight: 5.5g Appromix. Application: Original replace motor for Eachine Tyro 89 FPV Racing Drone Package Included:1x Eachine 1204 6000KV Motor ...

Specification: Brand Name: Eachine Model: Tyro 89 Item Name: 1204 6000KV 2-4S Brushless Motor Version: 30mm Cable with Connector Quantity: 4 PCKV: 6000KVLipo cell: 2-4 S Weight: 6.2g Maximum power: 148 W Configu-ration: 9N/12 P Shaft Diameter: 1.5mm Motor Stator Diameter: 12mm Motor Stator Thickness: 4mm Mounting holes distance: 9*9mm Mounting holes: φM2 Application: Original replace motor for Eachine Tyro 89 FPV Racing Drone Package Included:4x Eachine 1204 6000KV Motor 20x Screws ...

Eachine Tyro 99 210mm DIY Version FPV Racing Frame Kit 3K Carbon Fiber 6065 Aluminium Description: Brand name: Eachine Item name: Tyro 99 FPV Racing Frame Wheel base: 210mm Frame arm thickness: 5mm Bottom plate thickness: 2mm Side plate thickness: 2mm Frame kit

Material: 3K carbon fiber 6065 aluminium Frame weight: 106g Package included:1 x Tyro 99 FPV Racing Frame

...

Eachine Tyro 99 210mm DIY Version FPV Racing RC Drone w/ F4 OSD 30A BLHeli_S 700TVL Camera 5.8G 40CH 600m W VTXNote:1. This is the DIY version that comes unassembled.2. Make sure the antenna is installed at the output end before powering up to avoid damaging internal components;3. Note that the input voltage is within the specified range & is correct & correct to avoid damaging internal components;4. If the antenna is replaced, select a standing wave & a gain antenna for a longer transmission distance;5. Pay attention to classic protection during transportation & installation.6. Take-off weight is about 450g. Item Specification 210mm Frame Kit Wheel base: 210mm Frame arm thickness: 5mm Bottom plate thickness: 2mm Side plate thickness: 2mm Frame kit

Material: 3K carbon fiber 6065 aluminium 2206 2150KV Brushless Motor Motor KV: 2150RPM/VIdle current (Io/10V): 1.26 A Lipo cell: 3-5 S Weight: 31g Max continuous current: 31 A Max continuous power: 496 W Max thrust: 1050g (4S/5") Configu-ration: 12N/14 P Motor resistance (RM): 0.0572 Ω Stator diameter: 22mm Stator thickness: 6mm Motor diameter: 27.7mm Motor body length: 19.2mm Overall shaft length: 34.2mm Prop adapter shaft: M5 Bolt holes spacing: 16mm Bolt thread: M3 Propeller: 5-6 inch 4 IN 1 30A BLHeli_S ESCContinuous current: 30 A Burst Current: 40A (10S) Input voltage: 2-5SBEC: 5V 2A BECMain control chip: 48 Mhz EFM8BB2 Firmware: BLHeli_S supports Dshot 600MOS:5*6 Customized F4 Flight Controller Main control chip: STM32F405 Sensor: ICM20602 Power supply: 5 V Integ

...
