Eachine Wizard TS215 FPV Racing Drone Spare Part Run Cam Swift 2 1/3 CCD 600TVL Camera IR Blocked Description: Brand name: Run Cam Item name: Swift 2 600TVL Camera Image sensor: 1/3 SONY Super HAD II CCDHorizontal resolution: 600TVL, 4:3 Lens: 2.3mm 150 Signal system: PALIntegrated OSD: YESIntegrated MIC: YESS/N Ration: 60d B (AGC OFF) Electronic shutter speed: PAL:1/50~100, 000 Auto Gain control (AGC): YESBack light compensation (BLC): YESMin.illumination: 0.01 Lux/1.2FWDR: D-WDRDNR: 2DNRDay/ Night: Color / Auto / BWPower: DC 5 to 36 V Net weight: 14g Dimensions: 28.5mm * 26mm * 26mm Connector: JST-XH 1.25mm * 5P/2 P Package included:1 x Run Cam Swift 2 600TVL Camera ...

Eachine Wizard TS215 215mm FPV Racing RC Drone F4 5.8G 72CH 40A BLHeli_32 Run Cam Swift 2 Camera XM+ BNF PNPDescription: Item Specification Eachine Wizard TS215 Wheelbase: 215mm
Material: 3K carbon fiber Frame arm thickness: 4mm Top platethickness: 3mm Bottom platethickness: 3mm Artist: hydrographics transfer printing Version: optional BNF version & PNP version Weight: 329g (excluding battery) Firmware: OMNIBUS F4 SDPackage weight: 870g Package

Size: 243mmx 95mmx 262mm TS 40A BLHeli_32 Brushless ESCBEC: no Continuous current: 40 A Peak current (5S): 45 A Input voltage: 2-6 S Current sensor: built in LED indicator onboard, the light colors are adjustable. Supports Dshot 1200, Dshot 600, Dshot 300, Dshot 150.TS2306 2450KV Brushless Motor KV: 2450NO.OF cell: 3-5 S Thrust: 2300g (16V 6040 2-blade prop) Framework: 12N14 P Motor shaft: 5mm Weight: 32.5g Customized Omnibus F4 Flight Controller CPU: f 4STM32F405 Barometer: BMP280 Input voltage: 3-5 S Sensor: MPU6000 SPIWith SD slot Built in OSDBuilt in 5V 3A BEC5.8G 72CH25mw / 200mw / 500mw / 800mw VTXInput voltage: 7-24 V Extra

Features: smart audio, 0.01m W (parameter-adjusting mode) Power supply: 5V camera @ under 0.3A max. Output voltage: 25m W-100m A 200m W-200m A 500m W-260m A 800m W-300m A @ 12 V Range: up to 4km with omnidirectional RHCP antennas Antenna connector: MMCX, RP-SMAPort connector: JST, 4pin Dimensions: 30.5x 30.5mm Weight: 8.5g (excluding antenna)
Material: 128g double copper Adjustable 25mw / 200mw / 500mw / 800mw Supports smart audio (remote parameter adjustment) Run Cam Swift 2 Ca





...

Eachine Wizard TS215 215mm FPV Racing RC Drone F4 5.8G 72CH 40A BLHeli_32 Run Cam Swift 2 Camera Frsky Taranis X-Lite Transmitter XM+ RTFDescription: Item Specification Eachine Wizard TS215 Wheelbase: 215mm
Material: 3K carbon fiber Frame arm thickness: 4mm Top platethickness: 3mm Bottom platethickness: 3mm Artist: hydrographics transfer printing Version: RTFFirmware: OMNIBUS F4 SDTS 40A BLHeli_32 Brushless ESCBEC: no Continuous current: 40 A Peak current (5S): 45 A Input voltage: 3-5 S Current sensor: built in LED indicator onboard, the light colors are adjustable. Supports Dshot 1200, Dshot 600, Dshot 300, Dshot 150.TS2306 2450KV Brushless Motor KV: 2450NO.OF cell: 2-6 S Thrust: 2300g (16V 6040 2-blade prop) Framework: 12N14 P Motor shaft: 5mm Weight: 32.5g Customized Omnibus F4 Flight Controller CPU: f 4STM32F405 Barometer: BMP280 Input voltage: 3-5 S Sensor: MPU6000 SPIWith SD slot Built in OSDBuilt in 5V 3A BEC5.8G 72CH25mw / 200mw / 500mw / 800mw VTXInput voltage: 7-24 V Extra

Features: smart audio, 0.01m W (parameter-adjusting mode) Power supply: 5V camera @ under 0.3A max. Output voltage: 25m W-100m A 200m W-200m A 500m W-260m A 800m W-300m A @ 12 V Range: up to 4km with omnidirectional RHCP antennas Antenna connector: MMCX, RP-SMAPort connector: JST, 4pin Dimensions: 30.5x 30.5mm Weight: 8.5g (excluding antenna)
Material: 128g double copper Adjustable 25mw / 200mw / 500mw / 800mw Supports smart audio (remote parameter adjustment) Run Cam Swift 2 Camera IR Blocked Image sensor: 1/3 SONY Super HAD II CCDHorizontal resolution: 600TVL,



...

Eachine Wizard TS215 FPV Racing RC Drone Multirotor Spare Part Battery Plate Non-Slip Mat Description: Brand name: Eachine Item name: Battery Plate Non-Slip Mat Usage: for Eachine Wizard TS215 FPV Racing Drone Package included:1 x carbon fiber battery plate 1 x bigger non-slip mat 1 x smaller non-slip mat 2 x sponge mat ...

Eachine Wizard TS215 FPV Racing RC Drone Multirotor Spare Part 3mm Top Plate Carbon Fiber Description: Brand name: Eachine Item name: 3mm top plate Thickness: 3mm
Material: carbon fiber Quantity: 1 PCUsage: for Wizard TS215 FPV racing RC drone Package included:1 x 3mm top plate
...

Eachine Wizard TS215 FPV Racing RC Drone Multirotor Spare Part Antenna RP-SMA Male Connector Description: Brand name: Eachine Item name: antenna Quantity: 1 PCConncetor: RP-SMA Male Package included:1 x antenna ...

Eachine Wizard TS215 FPV Racing RC Drone Multirotor Spare Part Camera Side Plate 2 PCSDescription: Brand name: Eachine Item name: camera side plate Quantity: 2 PCSUsage: for Wizard TS215 FPV racing RC drone Package included:2 x camera side plate ...

Eachine Wizard TS215 FPV Racing RC Drone Multirotor Spare Part LED Light 4 PCSDescription: Brand name: Eachine Item name: LED light Quantity: 4 PCSUsage: for Eachine Wizard TS215 FPV Racing Drone Package included:4 x LED light ...

Eachine Wizard TS215 FPV Racing RC Drone Multirotor Spare Part Screw Set M3*14M3*12M3*6M3 Nut Description: Brand name: Eachine Item name: Screw Set Usage: for Eachine Wizard TS215 FPV racing RC drone Package included:4 x M3*14 screw 7 x M3*12 screw 3 x M3*6 countersunk screw 5 x M3 nut ...

Eachine Wizard TS215 FPV Racing RC Drone Multirotor Spare Part Standoffs 30mm 35mm Description: Brand name: Eachine Item name: Standoffs Front: 30mm, 2PCSBack: 35mm, 1 PCPackage included:2 x front standoffs 30mm 1 x back standoffs 35mm ...
