Eachine Wizard TS215 215mm FPV Racing Frame 4mm Frame Arms Carbon Fiber Description: Brand: Eachine Item name: wizard TS215 FPV racing frame
Material: carbon fiber Wheel base: 215mm Frame arm: 4mm thickness Thickness of upper plate: 3mm Thickness of lower plate: 3mm Frame weight: about 86g Note: Package doesnt include the flight controller. Without the flight controller it cant be assembled a TS215 frame kit. Package included:1 x Eachine wizard TS215 FPV racing frame
...

Eachine Wizard TS215 FPV Racing Drone Spare Part 5S 18.5V 1550m Ah 80C Lipo Battery XT60 Description: Brand name: Eachine Item name: 5S 18.5V 1550m Ah 80C Lipo Battery Capacity: 1550mah Cell: 5 S Discharge rate: 80 C Connector: XT60
Size: 84x 33x 45mm Weight: 239g Package included:1 x 5S 18.5V 1550m Ah 80C Lipo Battery
...

Eachine Wizard TS215 FPV Racing Drone Spare Part Run Cam Swift 2 1/3 CCD 600TVL Camera IR Blocked Description: Brand name: Run Cam Item name: Swift 2 600TVL Camera Image sensor: 1/3 SONY Super HAD II CCDHorizontal resolution: 600TVL, 4:3 Lens: 2.3mm 150 Signal system: PALIntegrated OSD: YESIntegrated MIC: YESS/N Ration: 60d B (AGC OFF) Electronic shutter speed: PAL:1/50~100, 000 Auto Gain control (AGC): YESBack light compensation (BLC): YESMin.illumination: 0.01 Lux/1.2FWDR: D-WDRDNR: 2DNRDay/ Night: Color / Auto / BWPower: DC 5 to 36 V Net weight: 14g Dimensions: 28.5mm * 26mm * 26mm Connector: JST-XH 1.25mm * 5P/2 P Package included:1 x Run Cam Swift 2 600TVL Camera ...

Eachine Wizard TS215 215mm FPV Racing RC Drone F4 5.8G 72CH 40A BLHeli_32 Run Cam Swift 2 Camera XM+ BNF PNPDescription: Item Specification Eachine Wizard TS215 Wheelbase: 215mm
Material: 3K carbon fiber Frame arm thickness: 4mm Top platethickness: 3mm Bottom platethickness: 3mm Artist: hydrographics transfer printing Version: optional BNF version & PNP version Weight: 329g (excluding battery) Firmware: OMNIBUS F4 SDPackage weight: 870g Package

Size: 243mmx 95mmx 262mm TS 40A BLHeli_32 Brushless ESCBEC: no Continuous current: 40 A Peak current (5S): 45 A Input voltage: 2-6 S Current sensor: built in LED indicator onboard, the light colors are adjustable. Supports Dshot 1200, Dshot 600, Dshot 300, Dshot 150.TS2306 2450KV Brushless Motor KV: 2450NO.OF cell: 3-5 S Thrust: 2300g (16V 6040 2-blade prop) Framework: 12N14 P Motor shaft: 5mm Weight: 32.5g Customized Omnibus F4 Flight Controller CPU: f 4STM32F405 Barometer: BMP280 Input voltage: 3-5 S Sensor: MPU6000 SPIWith SD slot Built in OSDBuilt in 5V 3A BEC5.8G 72CH25mw / 200mw / 500mw / 800mw VTXInput voltage: 7-24 V Extra

Features: smart audio, 0.01m W (parameter-adjusting mode) Power supply: 5V camera @ under 0.3A max. Output voltage: 25m W-100m A 200m W-200m A 500m W-260m A 800m W-300m A @ 12 V Range: up to 4km with omnidirectional RHCP antennas Antenna connector: MMCX, RP-SMAPort connector: JST, 4pin Dimensions: 30.5x 30.5mm Weight: 8.5g (excluding antenna)
Material: 128g double copper Adjustable 25mw / 200mw / 500mw / 800mw Supports smart audio (remote parameter adjustment) Run Cam Swift 2 Ca





...

Eachine Wizard TS215 215mm FPV Racing RC Drone F4 5.8G 72CH 40A BLHeli_32 Run Cam Swift 2 Camera Frsky Taranis X-Lite Transmitter XM+ RTFDescription: Item Specification Eachine Wizard TS215 Wheelbase: 215mm
Material: 3K carbon fiber Frame arm thickness: 4mm Top platethickness: 3mm Bottom platethickness: 3mm Artist: hydrographics transfer printing Version: RTFFirmware: OMNIBUS F4 SDTS 40A BLHeli_32 Brushless ESCBEC: no Continuous current: 40 A Peak current (5S): 45 A Input voltage: 3-5 S Current sensor: built in LED indicator onboard, the light colors are adjustable. Supports Dshot 1200, Dshot 600, Dshot 300, Dshot 150.TS2306 2450KV Brushless Motor KV: 2450NO.OF cell: 2-6 S Thrust: 2300g (16V 6040 2-blade prop) Framework: 12N14 P Motor shaft: 5mm Weight: 32.5g Customized Omnibus F4 Flight Controller CPU: f 4STM32F405 Barometer: BMP280 Input voltage: 3-5 S Sensor: MPU6000 SPIWith SD slot Built in OSDBuilt in 5V 3A BEC5.8G 72CH25mw / 200mw / 500mw / 800mw VTXInput voltage: 7-24 V Extra

Features: smart audio, 0.01m W (parameter-adjusting mode) Power supply: 5V camera @ under 0.3A max. Output voltage: 25m W-100m A 200m W-200m A 500m W-260m A 800m W-300m A @ 12 V Range: up to 4km with omnidirectional RHCP antennas Antenna connector: MMCX, RP-SMAPort connector: JST, 4pin Dimensions: 30.5x 30.5mm Weight: 8.5g (excluding antenna)
Material: 128g double copper Adjustable 25mw / 200mw / 500mw / 800mw Supports smart audio (remote parameter adjustment) Run Cam Swift 2 Camera IR Blocked Image sensor: 1/3 SONY Super HAD II CCDHorizontal resolution: 600TVL,



...

Eachine Wizard TS215 FPV Racing RC Drone Multirotor Spare Part 3mm Top Plate Carbon Fiber Description: Brand name: Eachine Item name: 3mm top plate Thickness: 3mm
Material: carbon fiber Quantity: 1 PCUsage: for Wizard TS215 FPV racing RC drone Package included:1 x 3mm top plate
...

Eachine Wizard TS215 FPV Racing RC Drone Spare Part 4mm Frame Arm Carbon Fiber Description: Brand name: Eachine Item name: 4mm frame arm Thickness: 4mm
Material: carbon fiber Quantity: 1 PCUsage: for Wizard TS215 FPV racing RC drone Package included:1 x 4mm frame arm
...

Eachine Wizard TS215 FPV Racing RC Drone Multirotor Spare Part Antenna RP-SMA Male Connector Description: Brand name: Eachine Item name: antenna Quantity: 1 PCConncetor: RP-SMA Male Package included:1 x antenna ...

Eachine Wizard TS215 FPV Racing RC Drone Multirotor Spare Part Camera Side Plate 2 PCSDescription: Brand name: Eachine Item name: camera side plate Quantity: 2 PCSUsage: for Wizard TS215 FPV racing RC drone Package included:2 x camera side plate ...

Eachine Wizard TS215 FPV Racing RC Drone Multirotor Spare Part LED Light 4 PCSDescription: Brand name: Eachine Item name: LED light Quantity: 4 PCSUsage: for Eachine Wizard TS215 FPV Racing Drone Package included:4 x LED light ...
