Eachine Stack-X F4 Flytower Spare Part 35A 4 In 1 ESC 2-6S BLHeli_S Dshot 600 Ready For FPV Racing Drone Description: Brand name: Eachine Item name: 35A 4 In 1 ESC BLHeli_SOperating voltage: 2-6S Lipo FC power: integrated Maximum continuous operating current: 4*35 A Maximum instantaneous operating current: 4*40 A Firmware version: BLHELI_S Dshot 16.5 J_H_xx firmware Board

Size: 36*36mm Weight: 13g Supports Oneshort 125 / Multishot 42 / Dshot 150 / 300 / 600 Supports Blheli Suite configurable Stack-X F4 35A 4in 1 ESC QUICK USER GUIDE V1 Package included:1 x Eachine Stack-X 35A 4 In 1 ESC BLHeli_S

...

Only US$8.15, buy best eachine stingpad 5.8g 16dbi high gain flat panel fpv antenna sma/rp-sma for receiver rc drone sale online store at wholesale price. ...

Only US$17.99, buy best eachine td 600 5.8ghz 40ch 25/200/600/800mw fpv transmitter with dvr support smart audio osd pitmode vtx for rc drone long range sale online store at wholesale price. ...

Eachine Tiny 32bits F3 Brushed Flight Control Board Based On SP RACING F3 EVO For Micro FPV Frame Description: Brand Name: Eachine Item Name: Tiny SPRACINGF3_EVO_BRUSHflightcontroller Dimension: 23mm*19.5mm*5mm Thickness: 1.2mm Weight: 2g
Features:1. F3_EVO_ Brush is in the revision on the basis of the F3 EVO SP RACING, it is a 32bits brush flight controller based on SP RACING F3 EVO firmware.2. The flight control support 1S (4.2V).3. Independent design of the circuit structure, comes with the Voltagecontrol technology, 1 Slipobatteryinput, the UART1/2/3output 5V, DSMportoutput 3.3V.4. Using STM32F303CCT6 + MPU6500, advanced hardware platform F3 guarantee more stable flight.5. Withalargecurrent NMOStransistors, operatingcurrentofupto 10 Aormore. Each Brushedmotorisequippedwithfreewheelingdiodes.6. Support for PPM, SBUS, DSM/DSM2/DSMX receiver input signal.7. In support of the world almost all hollow cup motor, including 1020 coreless motor. Notice: This Tiny F3EVO_ Brushflightcontrollerisonlyusefor BRUSHMOTOR, Notcompatiblefor BRUSHLESSMOTOR. Receiver configuration:1. DSM receiver soldered directly to the DSM interface 3.3V, GND, RX3, Enable Seria_RX for UART3 & Set Receiver mode RX_SERIAL, Select Spektrum 1024 (DSM/DSM2) or Spektrum 2048 (DSMX)in Cleanflightconfigurator.2. SBUSreceiverweldedtothe UART2GND, +5V, RX2. Then Enable Seria_RXand Set Receivermode RX_SERIAL, Select Sbussignalin Cleanflightconfigurator.3. PPMreceiverweldedtothe UART2GND, +5V, RX2. Thenset Receivermodeto RX_PPMin Cleanflightconfigurator.FIRMWARE FLASH Ste
...

Eachine Tiny QX90 Micro FPV Racing Quadcopter Spare Parts Carbon Fiber DIY Frame Kit Description: Brand Name: Eachine Item Name: DIY Frame Kit Item NO.: QX90F
Material: Carbon Fiber Wheelbase: 90mm Thickness:1mm Dimension: 118*118*70mm Net Weight: 8g Motor

Size: 8.5x 20mm
Features: Compatible with 55mm propeller Compatible with 8520 Coreless motor Can be used with 1S 3.7V lipo battery Recommanded Part: Propeller: 55mm Propeller Motor: 8520 Motor Battery: 3.7V 600m Ah Battery Flight Controller: F3 Controller Board Package Included:1 x Frame Kit



...

Eachine Tiny QX90 QX95 Micro Racing Quadcopter Spare Parts 5.8G 4 Leaves RHCP FPV Mushroom Antenna Description: Brand Name: Eachine Item Name: Antenna Type: RHCP
Features: Light weight, good effect & strong signal Suitable for Eachine Tiny QX90 QX95 Micro Racing Quadcopter Package Included:1 x Antenna
...

Eachine Tiny QX90C Micro FPV Racing Quadcopter Spare Parts Colorful DIY Frame Kit QX90C1 Description: Brand Name: Eachine Item Name: DIY Frame Kit Item NO.: QX90C1
Material: Plastic
Colour: Yellow, Black, Orange, Blue (Optional) Wheelbase: 90mm Thickness: 1mm Dimension: 118*118*70mm Net Weight: 3.9g Motor

Size: 8.5x 20mm
Features: Colorful, there are a variety of colors available. Compatible with 55mm propeller Compatible with 8520 Coreless motor Recommanded Part: Propeller: 55mm Propeller Motor: 8520 Motor Battery: 3.7V 600m Ah Battery Flight Controller: F3 Controller Board Package Included:1 x Frame Kit




...

Eachine Tiny QX95 Micro DIY Frame Kit 1.5mm 3K Carbon Fiber Only 8g Support 8520 Coreless Motor Description: Brand Name: Eachine Item Name: DIY Frame Kit Item NO.: QX95F
Material: Carbon Fiber Wheelbase: 95mm Thickness:1.5mm Dimension: 125*85*55mm Net Weight: 8g Motor

Size: 8.5x 20mm
Features: Using 3K carbon fiber board CNC processing. Small wheelbase 95mm, very small brushed motors can be utilized as the power source with small 55mm propellers. On these the top plate is fitted with an extra plate added to fit you FPV camera. Lightweight about 8g. Compatible with 55mm propeller 8520 Coreless motor Recommanded Part: Propeller: 55mm Propeller Motor: 8520 Motor Battery: 3.7V Lipo Battery Flight Controller:SP_RACING_F3 EVO Brushed FRF3_EVO_BRUSHED Flight Controller FLF3_EVO_BRUSHED Flight Controller DSF3_EVO_BRUSHED Flight Controller AIOF3_BRUSHED Flight Controller FPV Camera: Eachine TX03 Camera CM275T Camera Package Included:1 x Frame Kit



...

Eachine Tiny QX90 Micro FPV Racing Quadcopter Spare Parts 8.5x 20mm Coreless Motor Description: Brand Name: Eachine Item Name: Coreless Motor Item NO.: QX906 Motor Diameter: 8.5mm Motor Length: 20mm Shaft Diameter: 1.0mm Cable Length: 60mm Weight: about 5g Option: Clockwise Motor (With Red Blue wire), Anti-clockwise Motor (With Black White wire) Quantity: 1 pcs Usage: For Eachine Tiny QX90 Micro FPV Racing Quadcopter Package included:1 x motor ...

Eachine TRASHCAN 75mm Crazybee F4 PRO OSD 2S Whoop FPV Racing Drone 500mm Flying Racing Gate Door Apron Take OFF Landing Combo Specifications: Eachine TRASHCAN FPV Racing Drone Brand Name: Eachine Model Name:TRASHCANItem Name: 2S75mm Brushless Whoop racer drone BNF/PNPWheelbase: 75mm
Size: 98mm*98mm*36mm Weight: 33g (without battery) Weight:48g (with Original 1s 300mah lipo battery x 2) Spare parts specifications: Motor Mode: TC0803KV15000 Configu-ration: 9N12 P Stator Diamter: 8mm Stator Length: 3mm Shaft Diameter: 1mm Motor Dimension (Dia.* Len): 10.5mm*14.5mm Weight (g): 2.2g No.of Cells (Lipo): 1S-2 S Flight controller (Frsky version) CRAZYBEEF4 PRO FR Firmware target: Crazybee F4FRMCU: STM32F411CEU6 (100MHZ, 512K FLASH) Sensor: MPU-6000 (SPI connection) Board

Size: 28.5 * 28.5MMPower supply: 1-2 Sbattery input (DC 3.5-8.7V) Built-in 6A (each) Blheli_S 4in 1 ESC Dshot 600 ready Frsky version Built-in SPI Frsky receiver with telemetry (D8/D16 switchable) Flysky version Built-in SPIFlysky receiver with telemetry (AFHDS/AFHDS2 Aswitchable)DSM2/X Version built-in Serial-based DSM2/DSMX compatible satellite receiver No RX version need to add external Receiver Built-in Betaflight OSD (SPI Control) Built-in Current meter Max 28 A Current meter scale set to 1175 Built-in 5V 1A Buck / Boostwith LC filter Built-in voltage detection BLHELI_S pass-through Ready Taillight LED Ready Onboard 4in 1 ESCMCU upgraded to EFM8BB21 Power supply: 1-2S Li Po/ Li Po HV (3.5v/8.7v) Current: 6A continuous peak 7A (3 seconds) Support BLHeli Suite programmable F


...
