Eachine Tiny QX90 Micro FPV Racing Quadcopter Spare Parts 8.5x 20mm Coreless Motor Description: Brand Name: Eachine Item Name: Coreless Motor Item NO.: QX906 Motor Diameter: 8.5mm Motor Length: 20mm Shaft Diameter: 1.0mm Cable Length: 60mm Weight: about 5g Option: Clockwise Motor (With Red Blue wire), Anti-clockwise Motor (With Black White wire) Quantity: 1 pcs Usage: For Eachine Tiny QX90 Micro FPV Racing Quadcopter Package included:1 x motor ...

Eachine TRASHCAN 75mm Crazybee F4 PRO OSD 2S Whoop FPV Racing Drone 500mm Flying Racing Gate Door Apron Take OFF Landing Combo Specifications: Eachine TRASHCAN FPV Racing Drone Brand Name: Eachine Model Name:TRASHCANItem Name: 2S75mm Brushless Whoop racer drone BNF/PNPWheelbase: 75mm
Size: 98mm*98mm*36mm Weight: 33g (without battery) Weight:48g (with Original 1s 300mah lipo battery x 2) Spare parts specifications: Motor Mode: TC0803KV15000 Configu-ration: 9N12 P Stator Diamter: 8mm Stator Length: 3mm Shaft Diameter: 1mm Motor Dimension (Dia.* Len): 10.5mm*14.5mm Weight (g): 2.2g No.of Cells (Lipo): 1S-2 S Flight controller (Frsky version) CRAZYBEEF4 PRO FR Firmware target: Crazybee F4FRMCU: STM32F411CEU6 (100MHZ, 512K FLASH) Sensor: MPU-6000 (SPI connection) Board

Size: 28.5 * 28.5MMPower supply: 1-2 Sbattery input (DC 3.5-8.7V) Built-in 6A (each) Blheli_S 4in 1 ESC Dshot 600 ready Frsky version Built-in SPI Frsky receiver with telemetry (D8/D16 switchable) Flysky version Built-in SPIFlysky receiver with telemetry (AFHDS/AFHDS2 Aswitchable)DSM2/X Version built-in Serial-based DSM2/DSMX compatible satellite receiver No RX version need to add external Receiver Built-in Betaflight OSD (SPI Control) Built-in Current meter Max 28 A Current meter scale set to 1175 Built-in 5V 1A Buck / Boostwith LC filter Built-in voltage detection BLHELI_S pass-through Ready Taillight LED Ready Onboard 4in 1 ESCMCU upgraded to EFM8BB21 Power supply: 1-2S Li Po/ Li Po HV (3.5v/8.7v) Current: 6A continuous peak 7A (3 seconds) Support BLHeli Suite programmable F


...

Eachine TRASHCAN 75mm Crazybee F4 PRO OSD 2S Whoop FPV Racing Drone Caddx Eos 2 Adjustable Camera 25~200m W VTX Swtichable Specifications: Brand Name: Eachine Model Name:TRASHCANItem Name: 2S75mm Brushless Whoop racer drone BNF/PNPWheelbase: 75mm
Size: 98mm*98mm*36mm Weight: 33g (without battery) Take off weight:48g (with Original 1s 300mah lipo battery x 2) Spare parts specifications: Motor Mode: TC0803KV15000 Configu-ration: 9N12 P Stator Diamter: 8mm Stator Length: 3mm Shaft Diameter: 1mm Motor Dimension (Dia.* Len): 10.5mm*14.5mm Weight (g): 2.2g No.of Cells (Lipo): 1S-2 S Flight controller (Frsky version) CRAZYBEEF4 PRO FR Firmware target: Crazybee F4FR (Flysky version) CRAZYBEEF4 PRO FS Firmware target: Crazybee F4FS (DSM2/DSMX version) CRAZYBEEF4 PRO Firmware target: Crazybee F4DX (No RX version) CRAZYBEEF4 PRO FR Firmware target: Crazybee F4DXMCU: STM32F411CEU6 (100MHZ, 512K FLASH) Sensor: MPU-6000 (SPI connection) Board

Size: 28.5 * 28.5MMPower supply: 1-2 Sbattery input (DC 3.5-8.7V) Built-in 6A (each) Blheli_S 4in 1 ESC Dshot 600 ready Frsky version Built-in SPI Frsky receiver with telemetry (D8/D16 switchable) Flysky version Built-in SPIFlysky receiver with telemetry (AFHDS/AFHDS2 Aswitchable)DSM2/X Version built-in Serial-based DSM2/DSMX compatible satellite receiver No RX version need to add external Receiver Built-in Betaflight OSD (SPI Control) Built-in Current meter Max 28 A Current meter scale set to 1175 Built-in 5V 1A Buck / Boostwith LC filter Built-in voltage detection BLHELI_S pass-through Ready Taillight LED Read


...

Eachine TRASHCAN 75mm FPV Racing Drone Spare Part 3.8V 300m Ah 40C/80C 1-2S Lipo Battery PH2.0 Plug Specification: Brand name: Eachine Capacity: 300m Ah Voltage: 3.8v Continuous Discharge Rate: 40 C Instantaneous discharge rate: 80C
Size: 55mmx 11.5mmx 6.5mm Weight: 7.8g Connector: PH2.0* Notes: Need 2pcs batteries for Series circuit Package Included:1 x 3.8V 300m Ah 40C/80C Battery
...

Eachine TRASHCAN 75mm FPV Racing Drone Spare Part 5.8G 25m W~200MW Switchable VTX FPV Transmitter 3.3-5.5 V Specification: Brand name: Eachine Output power: 25~200mwswitchable Frequency: 40CHInput voltage: 3.3V 5.5 V Current consumption: 300m A (type) Antenna: RG178 antenna Frequency: 5.8 G Hz 5bands 40channels With Raceband Smart Audio ready Weight: 3g Package Included:1 x 25m W~200MW Switchable VTXQA: How to swich the frequency & channel? Frequency: Plug USB (Universal Serial Bus), connectbetaflight, goto CLIcommand:25mw: Setvtx_power=1save 100mw: Setvtx_power=2save 200mw: Setvtx_power=3save Channel: Setvtx_band=1-5 Setvtx_channel=1-8 ...

Eachine TRASHCAN 75mm FPV Racing Drone Spare Part Frame Kit 5.7g Specification: Brand name: Eachine Item name: Frame Kit Suitable for TRASHCAN 75mm FPV Racing Drone Weight: 5.7g Package Included:1 x Frame Kit ...

Eachine TRASHCAN 75mm FPV Racing Drone Spare Part Handbag Case Bag for 75mm RC Drone Specification: Brand name: Eachine Item name: Handbag Suitable for TRASHCAN 75mm FPV Racing Drone Package Included:1 x Handbag ...

Eachine TRASHCAN 75mm FPV Racing Drone Spare Part RC Head Cover Camera Canopy Specification: Brand name: Eachine Item name: Head Cover Camera Canopy Suitable for TRASHCAN 75mm FPV Racing Drone Weight: 2.6g Package Included:1 x Head Cover Camera Canopy ...

Eachine TRASHCAN 75mm FPV Racing Drone Spare Part Taillight LED Strip Light with Cable Wire Specification: Brand name: Eachine Item name:LED Strip Light Suitable for TRASHCAN 75mm FPV Racing Drone Weight: 0.4g Package Included:1 x LED Strip Light ...

Eachine TRASHCAN 75mm FPV Racing Drone Spare Part TC0803 15000KV 1-2S Brushless Motor Specification: Brand name: Eachine Mode: TC0803KV16000 No.of Cells (Lipo): 1S-2 S Configu-ration: 9N12 P Stator Diamter: 8mm Stator Length: 3mm Shaft Diameter: 1mm Motor Dimension (Dia.* Len): 10.5mm*14.5mm Weight (g): 2.2g Package Included:1 x TC0803KV16000 Brushless Motor ...
