Eachine TRASHCAN 75mm Crazybee F4 PRO OSD 2S Whoop FPV Racing Drone Caddx Eos 2 Adjustable Camera 25~200m W VTX Swtichable Specifications: Brand Name: Eachine Model Name:TRASHCANItem Name: 2S75mm Brushless Whoop racer drone BNF/PNPWheelbase: 75mm
Size: 98mm*98mm*36mm Weight: 33g (without battery) Take off weight:48g (with Original 1s 300mah lipo battery x 2) Spare parts specifications: Motor Mode: TC0803KV15000 Configu-ration: 9N12 P Stator Diamter: 8mm Stator Length: 3mm Shaft Diameter: 1mm Motor Dimension (Dia.* Len): 10.5mm*14.5mm Weight (g): 2.2g No.of Cells (Lipo): 1S-2 S Flight controller (Frsky version) CRAZYBEEF4 PRO FR Firmware target: Crazybee F4FR (Flysky version) CRAZYBEEF4 PRO FS Firmware target: Crazybee F4FS (DSM2/DSMX version) CRAZYBEEF4 PRO Firmware target: Crazybee F4DX (No RX version) CRAZYBEEF4 PRO FR Firmware target: Crazybee F4DXMCU: STM32F411CEU6 (100MHZ, 512K FLASH) Sensor: MPU-6000 (SPI connection) Board

Size: 28.5 * 28.5MMPower supply: 1-2 Sbattery input (DC 3.5-8.7V) Built-in 6A (each) Blheli_S 4in 1 ESC Dshot 600 ready Frsky version Built-in SPI Frsky receiver with telemetry (D8/D16 switchable) Flysky version Built-in SPIFlysky receiver with telemetry (AFHDS/AFHDS2 Aswitchable)DSM2/X Version built-in Serial-based DSM2/DSMX compatible satellite receiver No RX version need to add external Receiver Built-in Betaflight OSD (SPI Control) Built-in Current meter Max 28 A Current meter scale set to 1175 Built-in 5V 1A Buck / Boostwith LC filter Built-in voltage detection BLHELI_S pass-through Ready Taillight LED Read


...

Eachine TRASHCAN 75mm FPV Racing Drone Spare Part 3.8V 300m Ah 40C/80C 1-2S Lipo Battery PH2.0 Plug Specification: Brand name: Eachine Capacity: 300m Ah Voltage: 3.8v Continuous Discharge Rate: 40 C Instantaneous discharge rate: 80C
Size: 55mmx 11.5mmx 6.5mm Weight: 7.8g Connector: PH2.0* Notes: Need 2pcs batteries for Series circuit Package Included:1 x 3.8V 300m Ah 40C/80C Battery
...

Eachine TRASHCAN 75mm FPV Racing Drone Spare Part 5.8G 25m W~200MW Switchable VTX FPV Transmitter 3.3-5.5 V Specification: Brand name: Eachine Output power: 25~200mwswitchable Frequency: 40CHInput voltage: 3.3V 5.5 V Current consumption: 300m A (type) Antenna: RG178 antenna Frequency: 5.8 G Hz 5bands 40channels With Raceband Smart Audio ready Weight: 3g Package Included:1 x 25m W~200MW Switchable VTXQA: How to swich the frequency & channel? Frequency: Plug USB (Universal Serial Bus), connectbetaflight, goto CLIcommand:25mw: Setvtx_power=1save 100mw: Setvtx_power=2save 200mw: Setvtx_power=3save Channel: Setvtx_band=1-5 Setvtx_channel=1-8 ...

Eachine TRASHCAN 75mm FPV Racing Drone Spare Part Damping Ball Screws Shock Specification: Brand name: Eachine Item name: Screws + Shock Damping Ball Suitable for TRASHCAN 75mm FPV Racing Drone Package Included:1 x Screw set 4 x Damping Ball ...

Eachine TRASHCAN 75mm FPV Racing Drone Spare Part Frame Kit 5.7g Specification: Brand name: Eachine Item name: Frame Kit Suitable for TRASHCAN 75mm FPV Racing Drone Weight: 5.7g Package Included:1 x Frame Kit ...

Eachine TRASHCAN 75mm FPV Racing Drone Spare Part RC Head Cover Camera Canopy Specification: Brand name: Eachine Item name: Head Cover Camera Canopy Suitable for TRASHCAN 75mm FPV Racing Drone Weight: 2.6g Package Included:1 x Head Cover Camera Canopy ...

Eachine TRASHCAN 75mm FPV Racing Drone Spare Part Taillight LED Strip Light with Cable Wire Specification: Brand name: Eachine Item name:LED Strip Light Suitable for TRASHCAN 75mm FPV Racing Drone Weight: 0.4g Package Included:1 x LED Strip Light ...

Eachine TRASHCAN 75mm FPV Racing Drone Spare Part TC0803 15000KV 1-2S Brushless Motor Specification: Brand name: Eachine Mode: TC0803KV16000 No.of Cells (Lipo): 1S-2 S Configu-ration: 9N12 P Stator Diamter: 8mm Stator Length: 3mm Shaft Diameter: 1mm Motor Dimension (Dia.* Len): 10.5mm*14.5mm Weight (g): 2.2g Package Included:1 x TC0803KV16000 Brushless Motor ...

Eachine TRASHCAN 75mm FPV Racing Drone Spare Part XT30 Power Cable Wire for 2S Power Input Specification: Brand name: Eachine Item name:XT30 Power Cable Wire Suitable for TRASHCAN 75mm FPV Racing Drone Weight: 1.8g Package Included:1 x XT30 Power Cable Wire ...

Eachine Triangle D 5.8G 40CH 25/100/200/400m W Switchable Triangle AV FPV Transmitter VTX With DVRSupport Smart Audio Tramp for Tinywhoop Description: Brand: Eachine Model: Triangle D Item name: FPV Transmitter Input voltage: 5 V Current consumption: 337m A~615m A (type) Extra

Features: DVR/ Smart audio (Compatible with SA & TR) Power supply: 5V output for Camera Output power: 25m W/100m W/200m W/400m W switchable Antenna connector: IPEX (RG178 antenna) Cable connector: JST SH1.0 3pin for Camera JST SH1.0 5pin for Connect with Flight controller Compress Format: AVIVideo Output format: NTSCRecord video

Size: 1280x 720 Support TF card: Max.32 G Weight: 3.5g (excluding antenna) Dimensions: 29mm*29mm*40mm, 25.5 stackable hole Kit contents: 1*VTX, 3*cable, 1* Antenna, 1* Instructions Button control Channel select mode Channel select Select channels by simple short presses. Blue LED light on stands for CH1, short presses to change 8 channels sequentially. For CH2/3/4/5/6/7/8, Blue LED flicker once, it wont light on. Notice: Blue LED only light on for CH1 Band select Press button for 2S, Green LED will flash, then short presses to select 5 bands. Power select Press button for 8S, Red LED P1 will flash, then select power by simple short presses to select 25m W/100m W/200m W sequentially, For 100m W, Red LED flicker once, it wont light on; For 200m W Red LED flicker once, it wont light on. Pressthebuttonagain, Red LED lights together, Represents the highest power 400m W. Notice: Red LED only light on for 25m W.DVR Function Easily g



...
