Eachine TRASHCAN 75mm FPV Racing Drone Spare Part Damping Ball Screws Shock Specification: Brand name: Eachine Item name: Screws + Shock Damping Ball Suitable for TRASHCAN 75mm FPV Racing Drone Package Included:1 x Screw set 4 x Damping Ball ...

Eachine TRASHCAN 75mm FPV Racing Drone Spare Part Frame Kit 5.7g Specification: Brand name: Eachine Item name: Frame Kit Suitable for TRASHCAN 75mm FPV Racing Drone Weight: 5.7g Package Included:1 x Frame Kit ...

Eachine TRASHCAN 75mm FPV Racing Drone Spare Part Handbag Case Bag for 75mm RC Drone Specification: Brand name: Eachine Item name: Handbag Suitable for TRASHCAN 75mm FPV Racing Drone Package Included:1 x Handbag ...

Eachine TRASHCAN 75mm FPV Racing Drone Spare Part RC Head Cover Camera Canopy Specification: Brand name: Eachine Item name: Head Cover Camera Canopy Suitable for TRASHCAN 75mm FPV Racing Drone Weight: 2.6g Package Included:1 x Head Cover Camera Canopy ...

Eachine TRASHCAN 75mm FPV Racing Drone Spare Part Taillight LED Strip Light with Cable Wire Specification: Brand name: Eachine Item name:LED Strip Light Suitable for TRASHCAN 75mm FPV Racing Drone Weight: 0.4g Package Included:1 x LED Strip Light ...

Eachine TRASHCAN 75mm FPV Racing Drone Spare Part XT30 Power Cable Wire for 2S Power Input Specification: Brand name: Eachine Item name:XT30 Power Cable Wire Suitable for TRASHCAN 75mm FPV Racing Drone Weight: 1.8g Package Included:1 x XT30 Power Cable Wire ...

Eachine Triangle D 5.8G 40CH 25/100/200/400m W Switchable Triangle AV FPV Transmitter VTX With DVRSupport Smart Audio Tramp for Tinywhoop Description: Brand: Eachine Model: Triangle D Item name: FPV Transmitter Input voltage: 5 V Current consumption: 337m A~615m A (type) Extra

Features: DVR/ Smart audio (Compatible with SA & TR) Power supply: 5V output for Camera Output power: 25m W/100m W/200m W/400m W switchable Antenna connector: IPEX (RG178 antenna) Cable connector: JST SH1.0 3pin for Camera JST SH1.0 5pin for Connect with Flight controller Compress Format: AVIVideo Output format: NTSCRecord video

Size: 1280x 720 Support TF card: Max.32 G Weight: 3.5g (excluding antenna) Dimensions: 29mm*29mm*40mm, 25.5 stackable hole Kit contents: 1*VTX, 3*cable, 1* Antenna, 1* Instructions Button control Channel select mode Channel select Select channels by simple short presses. Blue LED light on stands for CH1, short presses to change 8 channels sequentially. For CH2/3/4/5/6/7/8, Blue LED flicker once, it wont light on. Notice: Blue LED only light on for CH1 Band select Press button for 2S, Green LED will flash, then short presses to select 5 bands. Power select Press button for 8S, Red LED P1 will flash, then select power by simple short presses to select 25m W/100m W/200m W sequentially, For 100m W, Red LED flicker once, it wont light on; For 200m W Red LED flicker once, it wont light on. Pressthebuttonagain, Red LED lights together, Represents the highest power 400m W. Notice: Red LED only light on for 25m W.DVR Function Easily g



...

Eachine TS130 Frame Spare Part 2mm Top Plate 3K Carbon Fiber for FPV Racing Drone Specification: Brand name: Eachine Item name: TS130 Frame Top Plate Thickness: 2mm
Material: 3K Carbon Fiber Artist: Hydrographics Transfer Printing Package Included:1 x TS130 Frame Top Plate
...

Eachine TS5823S 40CH 5.8G 200MW AV Transmitter Module RP-SMA Female Skyzone Upgrade Specification: Brand Name: Eachine Item Name: Transmitter Module Item NO.: TS5823 S Modulate: Wideband FM Modulate Video Format: NTSC/PALOutput Impedance:50 Ohm Output Power: 23-24d Bm Channel:40 CHOperating Voltage: 7V-24 V Supply Current: 190m A Operating Temperature: -10~85℃ Video Band Width: 0~8.0 MHz Audio Carrier Frequency: 6.5 MHz Video Input Level: 0.8~1.2 Vp-p Video Input Impedance: 75 Ohm Audio Input Level: 0.5~2.0 Vp-p Audio Input Impedance: 10K Ohm Connector: RP-SMA Female (Inner needle) Antenna Connector: RP-SMA Male (Inner hole) Dimension: 40mm x 23mm x 8mm Weight: 7.3g

Features:-40 channels-200m W RF power output-Smallest & lightest, easy to carry.-Super mini size & light weight, -Suitable for small multi-quadcopter, escpeically for DJIwizard series aircraft. Package Included:1 x TS5823S 40CH 5.8G 200MW RP-SMA Female Mini FPV Transmitter 1 x Antenna 1 x Gopro 3 video output cable 2 x connector cable 1 x Product

Specification Table



...

Eachine TS5828L Micro 5.8G 600m W 40CH Mini FPV Transmitter with Digital Display Description: User Manual Brand Name: Eachine Item Name: FPV Transmitter Channel: 40CHFrequency: 5.6G-5.9 G Current: 190m A/12 V Temp.: -10-85℃ Video Band
Width: 8 M Audio Band
Width: 6.5 M Antenna: RP-SMA
Size: 38x 18x 8mm Weight: 16g Band & Channel selection CHCH1CH2CH3CH4CH5CH6CH7CH8GROUPA5865MHZ5845MHZ5825MHZ5805MHZ5785MHZ5765MHZ5745MHZ5725MHZB5733MHZ5752MHZ5771MHZ5790MHZ5809MHZ5828MHZ5847MHZ5866MHZE5705MHZ5685MHZ5665MHZ5645MHZ5885MHZ5905MHZ5925MHZ5945MHZF5740MHZ5760MHZ5780MHZ5800MHZ5820MHZ5840MHZ5860MHZ5880MHZR5658MHZ5695MHZ5732MHZ5769MHZ5806MHZ5843MHZ5880MHZ5917MHZPackage Included:1 x Transmitter 1 x Antenna 1 x Cable 1 x User Manual


...
